Installation and Operation, cont'd
Specifi cations
Video
Gain ................................................ Selectable: 0.7 V (unity), or 0.75 V
Peaking ........................................... Selectable: 0 dB or 6 dB @100 MHz
Bandwidth ..................................... 350 MHz (-3 dB)
Output cable driving distance
Output ................................. Up to 250' (75 m) with Extron MHR cable
Local monitor ..................... Up to 100' (30 m) with Extron MHR cable

Video input

Number/signal type ..................... 1 VGA-UXGA RGBHV, RGBS, RGsB,
Connectors .................................... (1) 15-pin HD female
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ Analog, 0.3 V to 1.5 Vp-p with no offset at
Impedance ..................................... 75 ohms
Horizontal frequency .................... 15 kHz to 135 kHz
Vertical frequency .......................... 30 Hz to 170 Hz
Return loss ..................................... <-38 dB @ 5 MHz
DC offset (max. allowable)........... 1.0 V
Input coupling ............................... DC

Video output

Number/signal type ..................... 1 VGA-UXGA RGBHV, RGBS, RGsB,
Connectors ..................................... (2) 15-pin HD female
Nominal level ................................ 0.7 Vp-p for RGB at unity gain
Minimum/maximum levels ........ Analog, 0.3 V to 1.5 Vp-p (follows input)
Impedance ..................................... 75 ohms
Return loss ..................................... <-40 dB @ 5 MHz
DC offset ........................................ ±5 mV with input at 0 offset
Sync
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................... RGBHV, RGBS, RGsB, RsGsBs
Input level ..................................... 1.5 V to 5.0 Vp-p
12 P/2 DA2xi • Installation and Operation
(XGA resolution)
(XGA resolution)
RsGsBs input
unity gain
RsGsBs output; 1 VGA-UXGA RGBHV,
RGBS, RGsB, RsGsBs local monitor loop-
through (i.d. bits are passed through)
Output level .................................. TTL, 4 V to 5 Vp-p, unterminated
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms or 55 ohms, switchable (output
Max input voltage ........................ 5.0 Vp-p
Max. propagation delay ............... 60 ns
Max. rise/fall time ........................ 4 ns
Polarity............................................ Positive or negative (follows input)
General
Power ............................................. Supplied by an external power supply
External power supply ................. 100 VAC to 240 VAC, 50/60 Hz, external,
Power input requirements ........... 12 VDC
P/2 DA2xi ...................................... 0.1 A
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /
Rack mount .................................... Yes, with optional RSU 129 or RSB 129 1U
Enclosure type .............................. Metal
Enclosure dimensions .................. 1.0" H x 4.3" W x 3.0" D (quarter rack
Product weight .............................. 0.5 lbs (0.3 kg)
Shipping weight ........................... 3 lbs (2 kg)
Vibration ........................................ ISTA 1A in carton (International Safe
Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................... 30,000 hours
P/2 DA2xi • Installation and Operation
impedance resistors are 50 and 30 ohms)
or by pin 9 of the VGA input of a PC that
complies with VESA DCC version 3
autoswitchable; to 12 VDC, 1 A, regulated
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
rack shelf, part #60-190-01 or
60-604-01; RSU 126 or RSB 126 6" deep
rack shelf, part #60-190-10 or 60-604-10; or
the VersaTools ® RSF 123 or RSB 123 rack
shelf, part #60-190-20 or 60-604-20.
Also furniture mountable with optional
MBD 129 through-desk mount kit,
#70-077-02, or attachable to a projector
mount using an optional PMK 250
projector mount kit, #70-526-02.
wide) 2.5 cm H x 10.9 cm W x 7.6 cm D
(Depth excludes connectors.)
Transit Association)
13
