Extron electronics P/2 DA2xi MT User Manual

Maximum level (Hi-Z) ................ >+15 dBu (4.36 V), balanced at 1%
Maximum level (600 ohms) ........ >+9 dBm (2.18 V), balanced at 1%
General
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, 4.5 watts,
Power input requirements ......... 12 VDC, 0.2 A
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
Cooling .......................................... Convection, no vents
Rack mount ................................... Yes, with optional 1U, 9.5" deep rack shelf,
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.0" H x 4.3" W x 3.0" D (quarter rack
Product weight ............................. 0.5 lbs (0.3 kg)
Shipping weight ........................... 3 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort, The Netherlands
800.633.9876 714.491.1500 +800.3987.6673 +31.33.453.4040
FAX 714.491.1517 FAX +31.33.453.4050
www.extron.com
© 2008 Extron Electronics. All rights reserved.
THD+N, with external power supply
THD+N, with external power supply
external, autoswitchable;
to 12 VDC, 1 A, regulated
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
part #60-190-01 (RSU 129) or 60-604-01
(RSB 129); or VersaTools ® 3.5" deep rack
shelf, part #60-190-20 (RSF 123) or
60-604-20 (RSB 123)
Attachable to a projector mount with an
optional bracket kit, part #70-077-04
(PMK 200)
Also under-furniture mountable with
optional brackets #70-077-01 (standard)
wide)
(2.5 cm H x 10.9 cm W x 7.6 cm D)
(Depth excludes connectors.)
Transit Association)
Extron Electronics, Asia Extron Electronics, Japan
135 Joo Seng Rd. #04-01 Kyodo Building, 16 Ichibancho
PM Industrial Bldg., Singapore 368363 Chiyoda-ku, Tokyo 102-0082
+800.7339.8766 +65.6383.4400 Japan
FAX +65.6383.4664 +81.3.3511.7655 FAX +81.3.3511.7656
User's Guide
P/2 DA2xi MT
Distribution Amplifier
68-713-01 Rev. E
04 08
