Specifications

Return loss .................................... <-35dB @ 5 MHz

Video output

Number/signal type
IN3212 ............................... 2 composite video
IN3214 ............................... 4 composite video
Connectors
IN3212 ............................... 2 female BNC
IN3214 ............................... 4 female BNC
Nominal level ............................... 1V p-p at unity gain
Minimum/maximum levels ...... 0.3V to 3.5V p-p
Impedance .................................... 75 ohms
Return loss .................................... <-35dB @ 5 MHz
DC offset ....................................... ±8mV maximum with input at 0 offset
Sync
Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
General
Power ............................................. 110VAC or 220VAC, 50/60 Hz, 2 watts,
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
Rack mount ................................... Yes
Enclosure type .............................. Metal
Enclosure dimensions ................. 4.0" H x 5.6" W x 1.25" D
Product weight ............................. 0.8 lbs (0.3 kg)
Shipping weight .......................... 2 lbs (1 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Listings .......................................... ETL (UL1950)
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
