Extron electronics P/2 DA2xi User Manual

im Vertrieb von
General
External power supply .................. 100 VAC to 240 VAC, 50/60 Hz, external,
Power input requirements ............ 12 VDC
P/2 DA2x ............................ 0.1 A
P/2 DA2xi MT ................... 0.2 A
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /
Rack mount ..................................... Yes, with optional 1U rack shelf, part
Enclosure type ................................ Metal
Enclosure dimensions ................... 1.0" H x 4.3" W x 3.0" D (quarter rack wide)
Product weight ............................... 0.5 lbs (0.3 kg)
Shipping weight ............................. 3 lbs (2 kg)
Vibration .......................................... ISTA 1A in carton
Listings ............................................. UL, CUL
Compliances .................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ................................................ 30,000 hours
Warranty .......................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
FCC Class A Notice
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his
own expense.
Note: This unit was tested with shielded cables on the peripheral devices. Shielded
cables must be used with the unit to ensure compliance.
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort
USA The Netherlands
714.491.1500 +31.33.453.4040
www.extron.com Fax 714.491.1517 Fax +31.33.453.4050
www.camboard.de © 2005 Extron Electronics. All rights reserved.
autoswitchable; to 12 VDC, 1 A, regulated
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
#60-190-01 or 60-604-01; or VersaTools
shelf, part #60-190-20 or 60-604-20; also
under-furniture mountable with optional
brackets #70-077-01; or projector mountable
with bracket kit #70-077-04 (optional for
P/2 DA2xi, standard for P/2 DA2xi MT)
2.5 cm H x 10.9 cm W x 7.6 cm D
(Depth excludes connectors.)
(International Safe Transit Association)
Extron Electronics, Asia Extron Electronics, Japan
135 Joo Seng Road, #04-01 Kyodo Building
PM Industrial Building 16 Ichibancho
Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan
+65.6383.4400 +81.3.3511.7655
Fax +65.6383.4664 Fax +81.3.3511.7656
CAMBOARD Electronics
User's Guide
® rack
Tel. 07131 911201
Fax 07131 911203
P/2 DA2xi, P/2 DA2xi MT
Distribution Amplifiers
68-713-01 Rev. D
