Datamax M-Class Mark II Maintenance Manual page 85

Printers
Hide thumbs Also See for M-Class Mark II:
Table of Contents

Advertisement

Removal and Replacement
Screw
Inner
Platen
Bearing Plate
Block
4. Remove the Screw that secures the Outer Bearing Plate then remove the Outer Bearing
Plate and slide the Bushing(s) out of the Platen Block.
Outer
Bearing Plate
Platen &
Assist Rollers
Screw
Bushings
Platen
Block
4-21
