Step Action
Use the buttons to set
the Gain Number to 00
and then press ENTER.
Record the sensor
8 reading as a Label
Value for Gain Number
00 in a table (32 rows
by four columns, with
headings similar to
those shown below.)
Gain Number
00
01
02
...
31
Step Action
Use the buttons to
increment the Gain
Number by one and
9 then press ENTER.
Record the Label Value.
Repeat this process for
each Gain Number.
Gain Number
00
01
02
...
31
(continued)
Adjustments and Maintenance
Displayed Message
TRAN SENSOR GAIN
yyy (0 - 31)
Sample Calibration Table
Label Value TOF Value
252
Displayed Message
TRAN SENSOR GAIN
yyy (0 - 31)
Sample Calibration Table
Label Value TOF Value
252
250
248
...
09
2-16
Comment
This is the Label Value for a
gain setting of 00, where
"yyy" represents the current
sensor reading.
00
Difference Value
Comment
Remaining Label Values,
where "yyy" represents the
current sensor reading.
01
Difference Value
