Configuring the AP
2.6.2

Establishing Connection

To establish the PPP port connection on both APs:
1. Select Set System Configuration from the Main Menu.
2. Set the PPP Interface to
3. Use the SPACE BAR or LEFT/RIGHT-arrow keys to change and press
2.6.3

PPP with Modems

The PPP interface provides a connection using modems over a telephone
line. Connect modems to the APs with straight-through serial cables.
Designate one AP as the Originating AP and the other as the Answering AP .
Configure the Originating AP with dial-out information to the answering AP .
The answering AP waits for the originating AP to dial in to it.
Supported Modems for modems supported by the AP .
Dial out manually through the Special Functions menu or dial out
automatically on boot.
2.6.4

Originating AP

From the originating APs UI:
1. Select Set Serial Port Configuration from the Main Menu.
2. Set the Port Use parameter to
3. Set the Modem Connected parameter to
4. Set the Connect Mode to
5. Select Dialout Number and enter the dialout telephone number of the
6. Set the Dialout Mode to
68
ENTER to confirm.
answering AP (maximum 31 characters). This string matches what
follows a typical Hayes Smartmodem ATDT command. Possible
characters include pauses, numbers and letters.
documentation.
.
ON
.
PPP
.
Originate
.
Auto
Spectrum24 Access Point AP-3020 Product Reference Guide
See Appendix B:
.
Yes
Refer to the modem
