4. When the WLAP is in functional state, but one or more WLAP connections
5. When all WLAP connections are in Forward state:
Special cases:
•
•
Spectrum24 Access Point AP-3020 Product Reference Guide
are not in Forward state:
LED
Status
Serial
Wired LAN Attached
Wired LAN Activity
Wireless LAN Attached
Wireless LAN Activity
LED
Status
Serial
Wired LAN Attached
Wired LAN Activity
Wireless LAN Attached
Wireless LAN Activity
If the WLAP manual BSS_ID is NOT set and no other WLAP is found the
WLAP goes to the functional state.
If the WLAP manual BSS_ID is set and the specified WLAP not found, the
WLAP remains in FULL Scan state permanently. The LEDs have the
following indicator status permanently:
LED
Status
Serial
Wired LAN Attached
Wired LAN Activity
Wireless LAN Attached
Wireless LAN Activity
State
blinks regularly
blinks if activity occurs
on if Ethernet cable attached
blinks if activity occurs
blinks slowly
blinks if activity occurs
State
blinks regularly
blinks if activity occurs
on if Ethernet cable attached
blinks if activity occurs
on
blinks if activity occurs
State
on
off
off
off
blinks slowly
blinks slowly
Hardware Installation
135
