The standard antenna works for most office environments. Obtain additional
or higher performance antennas from Symbol. Contact a Symbol sales
representative to order the following models:
standard rubber antenna
single high performance antenna
twin high performance diversity antennas
mountable F-plane antenna
Symbol continues to add antenna options for Spectrum24 devices. Contact a
Symbol sales representative for available antenna options.
If installing two antennas, enable the Antenna Selection in the User Interface.
See 2.3 Access Point Installation on page 37.
4.4.1

Antenna Extension Cables

Symbol offers extension cables for AP antennas. Some range loss occurs
when increasing the distance between the antenna and the AP .
Model
25-19371-01
25-19371-02
To order extension cables contact a Symbol representative.
4.5

Power Options

•
•
Spectrum24 Access Point AP-3020 Product Reference Guide
Standard power supply Part Number: 50-24000-006
115/230VAC, 50/60Hz.
– US line cord Part Number: 23844-00-00
Remote power distribution system, Part Number: AP-PS-11
– Refer to application note AP-PS-01 located on the Symbol
Technologies web page.
Length Loss
6 ft 2.0 db
12 ft 4.0 db
Hardware Installation
ML 2499-APA1-00
ML 2499-HPA1-00
ML 2499-DVA1-00
ML 2499-PSA1-00
Range Loss
5%
10%
131
