Identify wired network problems:
3. No operation:
4. AP powered on but has no connection to the wired network:
5. Verify network wiring and topology for proper configuration:
Spectrum24 Access Point AP-3020 Product Reference Guide
Wireless LAN Attached
Wired LAN Activity
Wired LAN Attached
Serial
Status
– Verify AP configuration via Telnet, PPP or UI. Review procedures for
Ethernet and serial connection of the AP . Review AP firmware
revisions and update procedures.
– Verify network configuration by ensuring that there are no duplicate
IP addresses. Power down the device in question and ping the
assigned address of the device. Ensure no other device responds to
that address.
– Check connections for proper wiring.
– Check that the cables used have proper pinouts and connectors.
– Verify router configuration and filtration setting.
– Check that network band use does not exceed 37% of bandwidth.
– Verify MU operations.
– Confirm AP operation.
– Confirm AP and MU Net_ID (ESSID).
– Check that the radio driver loaded properly.
– Check that the MU PROTOCOL.INI or NET.CFG file is compatible
with the network operating system.
Off Exit the AP manufacturing
environment.
Off LAN adapter present.
Off Valid manufacturing
configuration exists.
Off Valid runtime code exists.
Blinks Bootup and runtime codes
continuously downloaded to AP flash
memory successful. Runtime
code controls the AP .
