Hardware Installation
4.8.1

WLAP mode LED display.

When in the WLAP mode this chart signifies the APs LED indicator status.
For the IEEE 802.11 protocol and APs using firmware version 4.00-20 or
above only.
1. After power up, system initialization begins:
2. When a WLAP begins a full scan:
3. When one or more WLAPs are found, but still in full scan state:
134
LED
Status
Serial
Wired LAN Attached
Wired LAN Activity
Wireless LAN Attached
Wireless LAN Activity
LED
Status
Serial
Wired LAN Attached
Wired LAN Activity
Wireless LAN Attached
Wireless LAN Activity
LED
Status
Serial
Wired LAN Attached
Wired LAN Activity
Wireless LAN Attached
Wireless LAN Activity
State
Blinks
Blinks if activity occurs.
on if Ethernet cable attached
Blinks if activity occurs
Off
Off
State
On
Off
Off
Off
Blinks slowly
Blinks slowly
State
On
Off
Off
Off
Blinks slowly
Off
