Monitoring Statistics
3.7

Ethernet Statistics

The AP keeps Ethernet performance statistics including packet transmission
and data retries until reset. The display also includes information used only
by the Symbol Support Center.
•
Packet display for Ethernet statistical units:
Packets Seen
Packets Forwarded
Discarded/NoMatch
Discarded/Forced
Discarded/Buffer
Discarded/CRC
Broadcast/Multicast
Individual Address
Packets Sent
Any Collision
110
Select Ethernet Statistics from the Main Menu to display:
Symbol Access Point
Packets Seen
Packets Forwarded
Discarded/NoMatch
Discarded/Forced
Discarded/Buffer
Discarded/CRC
Broadcast/Multicast
Individual Address
Refresh-[F1]
Ethernet Statistics
0 Packets Sent
0 Any Collisions
0 1 + Collisions
0 Maximum Collisions
0 Late Collisions
0 Defers
0
0
Timed-[F2]
packets received on Ethernet interface
packets forwarded from Ethernet interface to other
interfaces
packets discarded because of unknown destinations
(destinations not in the known list of database entries)
packets discarded because of the applied address filters
packets discarded because insufficient buffers in AP
packets discarded because of data errors
total broadcast or multicast packets received
packets received with designated individual addresses
total packets sent out
packets affected by at least one collision
Spectrum24 Access Point AP-3020 Product Reference Guide
138
0
0
0
0
0
Exit-[ESC]
