Page 1: Hardware Guide
53-0000080-03 06 September 2013 Brocade NetIron CES and Brocade NetIron CER Devices Hardware Guide Supported Release: Multi-Service IronWare R05.5.00... - Page 2 Export of technical data contained in this document may require an export license from the United States government. The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer programs that accompany it.
-
Page 3: Table Of Contents
Contents About This Document In this chapter ......... . . vii Audience . - Page 4 Chapter 2 Connecting to a Network Device Password assignment........21 IP address configuration.
- Page 5 Chapter 5 Hardware Maintenance Hardware maintenance schedule ......57 Power supply replacement ....... . . 57 Installation precautions and warnings .
- Page 6 Port specifications ........94 Console port pin assignments .
-
Page 7: About This Document
About This Document In this chapter • Audience............vii •... -
Page 8: Supported Hardware And Software
In this chapter Supported hardware and software The following hardware platforms are supported by this release of this guide: TABLE 1 Supported devices Brocade NetIron XMR Series Brocade MLX Series NetIron CES 2000 and NetIron CER 2000 Series Brocade NetIron XMR 4000 Brocade MLX-4 Brocade NetIron CES 2024C Brocade NetIron XMR 8000... -
Page 9: Document Conventions
In this chapter Document conventions This section describes text formatting conventions and important notice formats used in this document. Text formatting The narrative-text formatting conventions that are used are as follows: bold text Identifies command names Identifies the names of user-manipulated GUI elements Identifies keywords Identifies text to enter at the GUI or CLI italic text... -
Page 10: Notice To The Reader
In this chapter Notice to the reader This document may contain references to the trademarks of the following corporations. These trademarks are the properties of their respective companies and corporations. These references are made for informational purposes only. Corporation Referenced Trademarks and Products Microsoft Corporation Internet Explorer Mozilla Corporation... -
Page 11: Getting Technical Help Or Reporting Errors
In this chapter Getting technical help or reporting errors To contact Technical Support, go to http://www.brocade.com/services-support/index.page for the latest e-mail and telephone contact information. Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03... - Page 12 In this chapter Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 13: Introduction
Chapter Product Overview Introduction Network planners today have to expand and extend the range of services offered further into the edge of the network. This requires extending the intelligence and high-touch processing capabilities to the network edge— whether in a metro network, a campus network or in a data center. The challenge at the edge of the network is compounded by the need to flexibly define and easily manage customer services in an intuitive manner. - Page 14 Introduction • Brocade NetIron CES 2048FX — accommodates 48-port 100/1000 Hybrid Fiber (HF) model with 2x10G XFP uplink ports FIGURE 1 Brocade NetIron CES 2024C-4X FIGURE 2 Brocade NetIron CES 2024F-4X FIGURE 3 Brocade NetIron CES 2024C FIGURE 4 Brocade NetIron CES 2048CX There are also fourteen models in the NetIron Carrier Ethernet Router (CER and CER-RT) 2000 Series: •...
- Page 15 Introduction • Brocade NetIron CER- RT 2024C — accommodates 24-port 10/100/1000 Copper RJ45 model with 4 combination 100/1000 Hybrid Fiber (HF) ports and an optional field upgradeable 2x10G uplink slot. This device has the ability to simultaneously store up to 1.5 million IPv4 routes and up to 256,000 IPv6 routes •...
- Page 16 Introduction • Brocade NetIron CER- RT 2048FX — accommodates 48-port 100/1000 Hybrid Fiber (HF) model with 2x10G XFP uplink ports. This device has the ability to simultaneously store up to 1.5 million IPv4 routes and up to 256,000 IPv6 routes. FIGURE 5 Brocade NetIron CER 2024C-4X-RT FIGURE 6...
-
Page 17: Product Overview
Product overview Product overview The Brocade NetIron CES 2000 Series is a compact 1 RU, multi-service edge or aggregation switch with a powerful set of capabilities that combine performance with rich functionality at the network edge. The Brocade NetIron CES 2000 Series switch offers network planners a broad set of high performance IPv4, Classic Layer 2, Provider Bridge (PB) and Provider Backbone Bridge (PBB) functionalities in the same device. -
Page 18: Upgrade Applications
Upgrade applications 802.1ah), Connectivity Fault Management (IEEE 802.1ag) and Service OAM, along with Ethernet Service Instance (ESI). The Brocade NetIron CER -RT features the same upgradeability to 10 GbE with full MPLS capabilities as the original Brocade NetIron CER, and has the ability to simultaneously store up to 1.5 million IPv4 routes and up to 256,000 IPv6 routes. -
Page 19: Brocade Netiron Ces 2024C-4X
Hardware features Brocade NetIron CES 2024C-4X The Brocade NetIron CES 2024C-4X switch has twenty-four 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, 4-port 10 GbE SFP+ module, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. -
Page 20: Brocade Netiron Ces 2024C
Hardware features Brocade NetIron CES 2024C The Brocade NetIron CES 2024C switch has twenty-four 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, one module slot for an optional field upgradable 2-port 10 GbE XFP module, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. -
Page 21: Brocade Netiron Ces 2048C
Hardware features Brocade NetIron CES 2048C Brocade NetIron CES 2048C (Copper) switch has forty-eight 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included FIGURE 15 Brocade NetIron CES 2048C device... -
Page 22: Brocade Netiron Ces 2048F
Hardware features Brocade NetIron CES 2048F Brocade NetIron CES 2048F (Fiber) has forty-eight 100/1000 MbE SFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. -
Page 23: Brocade Netiron Cer 2024F
Hardware features The Brocade NetIron CER-RT 2024C router has more memory to support 1.5M routes, twenty-four 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, one module slot for an optional field upgradable 2-port 10 GbE XFP module, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. -
Page 24: Brocade Netiron Cer 2048C
Hardware features Brocade NetIron CER 2048C Brocade NetIron CER 2048C (Copper) router has forty-eight 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included Brocade NetIron CER-RT 2048C (Copper) router has more memory to support 1.5M routes, forty-eight 10/100/1000 MbE RJ45 ports plus four combination 100/ 1000 MbE SFP ports, one... -
Page 25: Brocade Netiron Cer 2048F
Hardware features Brocade NetIron CER 2048F Brocade NetIron CER 2048F (Fiber) has forty-eight 100/1000 MbE SFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. -
Page 26: Control Features
Hardware features Control features The front panel on each device has a combination of the following control features: • Serial Management Interface (the port labeled Console) • 10/100/1000 ports with RJ-45 copper connectors • 100/1000 Hybrid Fiber (HF) ports • 100/1000 ports with mini-GBIC slots for SFP MSA-compliant fiber transceivers •... - Page 27 Hardware features TABLE 4 LEDs for 10-Gbps Ethernet ports Port State Meaning 10-Gbps Port LEDs on devices with two 10-Gbps ports Left hand port The port is connected. No fiber port connection exists. Blinking Traffic is being transmitted and received on the fiber port Bottom Right hand port...
- Page 28 Hardware features 10-Gbps ports The Brocade NetIron CES 2048C-4X, Brocade NetIron CES 2048F-4X, Brocade NetIron CER 2048C-4X-RT, and the Brocade NetIron CER 2048F-4X-RT come with four 10-Gigabit Ethernet ports installed. The four 10-Gigabit Ethernet uplink ports support 10-Gigabit Small Form Factor Pluggable (SFP+) MSA-compliant optical transceivers The Brocade NetIron CES 2048CX, Brocade NetIron CES 2048FX, Brocade NetIron CER 2048CX, and the Brocade NetIron CER 2048FX come with two 10-Gigabit Ethernet ports installed.
- Page 29 Hardware features TABLE 5 SFP-compliant transceivers for the 100/1000 Ethernet interface module (Continued) Part number Description E1MG-100BXU 100Base-BXU SFP optic single-mode fiber, 1310nm, LC connector. This optic can only be connected to an E1MG-100BXD. E1MG-100BXD 100Base-BXD SFP optic single-mode fiber, 1490nm, LC connector. This optic can only be connected to an E1MG-100BXU.
-
Page 30: Network Interfaces
Hardware features • Port 2/2 (optional 10-GbE uplink port) • Port 2/3 (optional 10-GbE uplink port) • Port 2/4 (optional 10-GbE uplink port) Brocade NetIron CES 2048 and Brocade NetIron CER 2048 devices with 48 ports: • Ports 1/1 –1/24 •... - Page 31 Hardware features The following sections provide further details about the power supplies for the devices: • Power status LEDs are listed in “Observing the power status LEDs” on page 44. • Hardware specifications for the power supplies are listed in “Hardware specifications”...
-
Page 32: Cooling System And Fans
Hardware features Cooling system and fans This section describes the fans in the devices with 6 fans. Figure 27 shows the cooling fans. FIGURE 27 Cooling Fans Six cooling fans The device cooling fans use pull configuration to move the air from the front to the back of the device. -
Page 33: Connecting To A Network Device
Chapter Connecting to a Network Device Password assignment DANGER The procedures in this manual are for qualified service personnel. By default, the device’s CLI is not protected by passwords. To secure CLI access, Brocade strongly recommends assigning passwords. (For additional information on security, refer to Foundry Security Guide.) The CLI contains the following access levels: •... -
Page 34: Ip Address Configuration
IP address configuration Brocade# configure terminal Brocade(config)# 3. Enter the following command to set the super-user password. Brocade(config)# enable super-user-password <text> NOTE You must set the super-user password before you can set other types of passwords. 4. Enter the following commands to set the port configuration and read-only passwords. Brocade(config)# enable port-config-password <text>... -
Page 35: Assigning An Ip Address To A Management Interface
IP address configuration The following sub-net masks are supported by the devices: • To enter a classical network mask, enter the mask in IP address format. For example, enter “209.157.22.99 255.255.255.0” for an IP address with a Class-C sub-net mask. •... -
Page 36: Assigning An Ip Address To An Interface, Virtual Interface, Or Loopback
IP address configuration Assigning an IP address to an interface, virtual interface, or loopback As you have done with other devices, you must assign an IP address to each interface and virtual interface over which user packets are routed. You can also assign an IP address to a loopback interface, which is generally used for testing and diagnostic purposes. -
Page 37: Enabling And Disabling The Interfaces
Management port function overview Enabling and disabling the interfaces By default, all interfaces are disabled. To enable an interface, you must enter the enable command at the appropriate interface configuration level of the CLI. For example, to enable the management interface, enter the enable command at the management interface configuration level of the CLI. - Page 38 Device connection For information on cabling a fiber-optic module, see “Cabling a fiber optic module” on page 72. For information on cleaning a fiber-optic module, see “Fiber optic connector cleaning” on page 73. Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 39: Installation
Chapter Installation System unpacking DANGER The procedures in this manual are for qualified service personnel. The Brocade systems ship with all of the following items. Please review the list below and verify the contents. If any items are missing, please contact the place of purchase. Package contents The package contains the following: •... -
Page 40: Summary Of Installation Tasks
Summary of installation tasks Summary of installation tasks Follow the steps listed below to install your Brocade device. Details for each of the steps highlighted below are provided in this chapter and in the following chapter. TABLE 8 Summary of installation tasks Task Task Where to find more information... -
Page 41: Installation Precautions
Installation precautions Installation precautions Follow these precautions when installing the unit. DANGER Risk of explosion if battery is replaced by an incorrect type. Replace the battery only with the same or equivalent type recommended by the manufacturer. Lithium battery is a long life battery and it is very possible that you will never need to replace it. -
Page 42: Power Precautions
Installation precautions Power precautions CAUTION Use a separate branch circuit for each AC power cord, which provides redundancy in case one of the circuits fails. CAUTION Ensure that the device does not overload the power circuits, wiring, and over-current protection. To determine the possibility of overloading the supply circuits, add the ampere (amp) ratings of all devices installed on the same circuit as the device. - Page 43 Installation precautions CAUTION The power supply is designed exclusively for use with the Brocade NetIron CES and Brocade NetIron CER devices. The power supply produces extensive power. Installing the power supply in a device other than the Brocade NetIron CES and Brocade NetIron CER 2000 series device will cause extensive damage to your equipment.
-
Page 44: Installation Site Preparation
Installation site preparation CAUTION For the DC input circuit (DC power supply part number RPS9-DC), make sure there is a 20 amp circuit breaker, minimum 48Vdc, double pole, on the input to the power supply. The input wiring for connection to the product should be copper wire, 12 AWG, marked VW-1, and rated minimum 90 C. -
Page 45: Redundant Power Supply Installation
Redundant power supply installation Redundant power supply installation The Brocade device ships with one alternating-current (AC) power supply or direct-current (DC) power supply. All models have two power supply slots, enabling you to install a second power supply for redundancy. If desired, you can install a second supply for redundancy. CAUTION Changes or modifications made to this device that are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 46 Redundant power supply installation Follow the procedure given below to install an AC power supply. 1. If necessary, remove the power supply locking screws located in the upper left and the bottom right of the device (illustrated below). FIGURE 28 Power supply installation Power supply Grounding terminals...
-
Page 47: Installing A Dc Power Supply
Redundant power supply installation 9. Connect the plug end of the power cord into outlet. CAUTION For the NEBS compliant installation of a Brocade NetIron CES 2000 or Brocade NetIron CER 2000 Series devices with AC and DC system use a ground wire of at least #6 American Wire Gauge (AWG). - Page 48 Redundant power supply installation FIGURE 29 The DC power supply 4. Insert the wires into the DC wiring assembly (Figure 30). 5. Use the wire tightening screws to secure the wires. 6. Insert the DC connector with wires to the power supply and tighten the two assembly screws. FIGURE 30 The DC wiring assembly Wire tightening screws...
- Page 49 Redundant power supply installation With one hand, hold the bar on the front panel of the power supply. With the other hand, support the underside of the power supply, and insert the power supply into the empty power supply slot. Press until the supply is completely in the slot, so that the connectors on the back of the supply are fully engaged with the pins on the power backplane (Figure 28).
- Page 50 Redundant power supply installation CAUTION For the NEBS compliant installation of a Brocade NetIron CES and Brocade NetIron CER 2000 series devices with AC and DC system use a ground wire of at least 6 American Wire Gauge (AWG). The ground wire should have an agency-approved crimped connector (provided with the chassis) attached to one end, with the other end grounded to either a common bonding network or an isolated bonding network.
-
Page 51: Device Installation
Device installation Device installation You can install devices on a desktop, or in an equipment rack. Installing the device on a desktop Follow the steps for desktop installation. 1. Set the device on a flat desktop, table, or shelf. Make sure that adequate ventilation is provided for the system –... - Page 52 Device installation 5 Inch offset rack mount position FIGURE 33 5 Inch offset rack mount position Mid rack mount position FIGURE 34 Mid rack mount position Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
- Page 53 Device installation Reverse rack mount position FIGURE 35 Reverse rack mount position Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 54: Installation Steps
Device installation FIGURE 36 Installing the Brocade device in a rack Installation steps 1. Mount the device in the rack as illustrated in Figure 2. Using a 2-hole grounding lug and a minimum #6 AWG grounding wire, ground the chassis to either a common bonding network or an isolated bonding network. -
Page 55: System Power
System power System power After you complete the physical installation of the system, you can power on the system. Powering on the system 1. Ensure that all power supplies are fully and properly inserted and no power supply slots are uncovered. -
Page 56: Operation Verification
Operation verification Operation verification After you have installed any redundant power supplies, verify that the device is working properly by plugging it into a power source and verifying that it passes its self test. If your device has more than one power supply installed, repeat this procedure for each power supply. - Page 57 Operation verification TABLE 9 LEDs for power and fan status for the 2024 models (Continued) Position State Meaning Power Supplies DC - same indications for both DC power supplies Right side of front No DC power. panel Amber Supply has DC power, but output is not enabled. Green Supply has DC power, is enabled, and has good output.
-
Page 58: Pc Or Terminal Attachment
PC or terminal attachment The software regularly polls the hardware for power status information. You can display the status information from any management session. In addition, the software automatically generates a Syslog message and SNMP trap if a status change occurs. PC or terminal attachment To assign an IP address, you must have access to the Command Line Interface (CLI). - Page 59 PC or terminal attachment 1. Make sure the cable is securely connected to your PC and to the system. 2. Check the settings in your terminal emulation program. In addition to the session settings listed above, make sure the terminal emulation session is running on the same serial port you attached to the system.
- Page 60 PC or terminal attachment Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 61: Device Management Applications Familiarization
Chapter Device Management Applications Familiarization Management application overview This chapter describes the different applications you can use to manage the devices. The Brocade devices support the same management applications as other devices. As with other devices, you can manage a device using any of the following applications: •... -
Page 62: Online Help
CLI Functionality Online help To display a list of available commands or command options, enter “?” or press Tab. If you have not entered part of a command at the command prompt, all the commands supported at the current CLI level are listed. If you enter part of a command, then enter “?” or press Tab, the CLI lists the options you can enter at this point in the command string. -
Page 63: Searching And Filtering Output From Cli Commands
CLI Functionality TABLE 11 CLI line editing commands Ctrl-key combination Description Ctrl-A Moves to the first character on the command line. Ctrl-B Moves the cursor back one character. Ctrl-C Escapes and terminates command prompts and ongoing tasks (such as lengthy displays), and displays a fresh command prompt. Ctrl-D Deletes the character at the cursor. - Page 64 CLI Functionality NOTE The vertical bar (|) is part of the command. Note that the regular expression specified as the search string is case sensitive. In the example above, a search string of “Internet” would match the line containing the IP address, but a search string of “internet”...
- Page 65 CLI Functionality Brocade# ? append Append one file to another attrib Change file attribute boot Boot system from bootp/tftp server/flash image Change current working directory chdir Change current working directory clear Clear table/statistics/keys clock Set clock configure Enter configuration mode copy Copy between flash, tftp, config/code Copy file commands...
-
Page 66: Using Special Characters In Regular Expressions
CLI Functionality --More--, next page: Space, next line: Return key, quit: Control-c -telnet The filtered results are displayed. filtering... sync-standby Sync active flash (pri/sec/mon/startup config/lp images) to standby if different terminal Change terminal settings traceroute TraceRoute to IP node undelete Recover deleted file whois WHOIS lookup... - Page 67 CLI Functionality TABLE 12 Special characters for regular expressions (Continued) Character Operation A dollar sign matches on the end of an input string. For example, the following regular expression matches output that ends with “deg”: deg$ An underscore matches on one or more of the following: •...
- Page 68 CLI Functionality Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 69: Hardware Maintenance
Chapter Hardware Maintenance Hardware maintenance schedule DANGER The procedures in this manual are for qualified service personnel. The Brocade device requires minimal maintenance for its hardware components. Brocade recommends cleaning the fiber-optic connectors on a fiber-optic port and the connected fiber cable each time you disconnect the cable. -
Page 70: Installation Precautions And Warnings
Power supply replacement Installation precautions and warnings Follow these precautions when installing a power supply in the Brocade device. DANGER Before beginning the installation, refer to the precautions in “Power precautions” on page 30. CAUTION Do not install the device in an environment where the operating ambient temperature might exceed C (104 CAUTION... -
Page 71: Ac Power Supply
Power supply replacement This command displays status information for the power supplies and the fans. The power supplies are numbered from left to right. These numbers assume you are facing the front of the device, not the rear. If the display indicates “Installed (Failed)” for any of the slots, the power supply installed in that particular slot has failed. - Page 72 Power supply replacement Removing the AC power supply Required tools You will need the following tool to perform this procedure: • #2 Phillips-head screwdriver The following procedures are required when removing an AC power supplies from a device. 1. Unplug the power supply from the power source. 2.
-
Page 73: Installing The Ac Power Supply
Power supply replacement FIGURE 39 Removing the power supply from the device 5. Continue to pull the power supply until it is removed from the device. 6. Place the power supply in an anti-static bag for storage. Insert a new supply, or place and screw in a cover plate over the empty power supply. Refer to “Installing the AC power supply”... - Page 74 Power supply replacement FIGURE 40 Power supply installation CAUTION Make sure you insert the power supply right-side up. It is possible to insert the supply upside down, although the supply will not engage with the power backplane when upside down. The power supply is right-side up when the manufacturer label is on the top.
- Page 75 Power supply replacement FIGURE 41 DC power supply screws Chassis attachment screws Assembly screws 4. Unscrew the chassis attachment screws to unlock the power supply itself (Figure 41). FIGURE 42 The DC wiring assembly Wire tightening screws Assembly screws Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
- Page 76 Power supply replacement 5. Pull the power supply outward once the screws have been unscrewed. This will disconnect the power supply from the backplane. Pull it completely free of the chassis. 6. Place the power supply in an anti-static bag for storage. Insert a new supply, or place and screw in a cover plate over the empty power supply.
- Page 77 Power supply replacement FIGURE 44 The DC wiring assembly Wire tightening screws Assembly screws With one hand, hold the bar on the front panel of the power supply. With the other hand, support the underside of the power supply, and insert the power supply into the empty power supply slot.
- Page 78 Power supply replacement FIGURE 45 DC power supply screws Chassis attachment screws Assembly screws 9. Connect the wire to your DC power source, making sure to connect the -48V cable to the negative terminal on the power supply and the 0V cable to the positive terminal as marked on the power supply.
-
Page 79: Verifying Proper Operation
Power supply replacement CAUTION To insure adequate bonding when attaching the provided Panduit LCD6-10AF two-hole ground lug, a minimum of 20 PSI of torque is required to be applied to the mounting hardware used to attach the ground lug. Use a star washer to ensure an NEBS compliant connection. Verifying proper operation To verify the proper operation of the power supply after power on, you can observe the LEDs on the power supply. -
Page 80: 10-Gigabit Ethernet Module Installation Or Replacement
10-Gigabit Ethernet module installation or replacement The LEDs for Fan, PS1 and PS2 are located on the right side of the front panel for Brocade NetIron CES and Brocade NetIron CER 2024 models (On the Brocade NetIron CES 2048 and Brocade NetIron CER 2048 models, these LEDs are located on the left side of the front panel). -
Page 81: Removing A 2 X10-Gigabit Ethernet Module
Replacing the fan tray CAUTION For safety reasons, the ESD wrist strap should contain a series 1 Meg ohm resistor Removing a 2 x10-Gigabit Ethernet module Follow the procedure given below while removing a 2 x10-Gigabit Ethernet module. 1. Power off the Brocade device. 2. -
Page 82: Fiber Optic Module Replacement
Fiber optic module replacement To replace the Brocade fan tray, follow these steps. 1. Power down and unplug the chassis. 2. Unscrew the two screws that secure the fan tray to the chassis. FIGURE 46 Replacing the fan tray 3. Slide the fan tray out 4. -
Page 83: Installing A New Fiber Optic Module
Fiber optic module replacement CAUTION For safety reasons, the ESD wrist strap should contain a series 1 Meg ohm resistor. • The protective covering that you removed from the fiber optic module when you initially installed the module. Follow the steps given below to remove a fiber optic module from a Gigabit Ethernet or 10-Gigabit Ethernet port. -
Page 84: Cabling A Fiber Optic Module
Fiber optic module replacement CAUTION All fiber-optic interfaces use Class 1 Lasers. CAUTION For safety reasons, the ESD wrist strap should contain a series 1 Meg ohm resistor. Perform the following tasks to install a fiber optic module. 1. Put on the ESD wrist strap and ground yourself by attaching the clip end to a metal surface (such as an equipment rack) to act as ground. -
Page 85: Fiber Optic Connector Cleaning
Fiber optic connector cleaning The tunable 10 GbE dense wavelength-division multiplexing (DWDM) SFP+ modular optic (part number 10G-SFPP-ZRD-T) can be configured through the CLI to use C-band channels 1 - 102 for flexible metro or campus Ethernet links that reach up to 80 km. For 10-Gigabit Ethernet DWDM interfaces only, configure full C-band tunable optics as shown below. - Page 86 Fiber optic connector cleaning Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 87: Regulatory Statements
Appendix Regulatory Statements U.S.A. This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. -
Page 88: Japan
Japan Japan The following statements apply to the Brocade devices. English translation of above statement This is Class A product based on the standard of the Voluntary Control Council For Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. -
Page 89: Korea
Korea Korea The following statement applies to the Brocade devices. English translation of above statement Class A device (Broadcasting Communication Device for Office Use): This device obtained EMC registration for office use (Class A), and may be used in places other than home. Sellers and/or users need to take note of this. -
Page 90: China
China China Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03... -
Page 91: Caution And Danger Notices
Appendix Caution and Danger Notices The caution and danger notices that appear in this manual are listed below in English, German, French, and Spanish. Cautions A caution calls your attention to a possible hazard that can damage equipment. “Vorsicht” weist auf die Gefahr einer möglichen Beschädigung des Gerätes in. Une mise en garde attire votre attention sur un risque possible d'endommagement de l'équipement. - Page 92 Cautions CAUTION Make sure the air flow around the front, sides, and back of the device is not restricted. VORSICHT Stellen Sie sicher, dass an der Vorderseite, den Seiten und an der Rückseite der Luftstrom nicht behindert wird. MISE EN GARDE Vérifiez que rien ne restreint la circulation d'air devant, derrière et sur les côtés du dispositif et qu'elle peut se faire librement.
- Page 93 Cautions CAUTION Make sure you insert the power supply right-side up. It is possible to insert the supply upside down, although the supply will not engage with the power backplane when upside down. The power supply is right-side up when the power connector is on the left and the fan vent is on the right.
- Page 94 Cautions CAUTION Use the erase startup-config command only for new systems. If you enter this command on a system you have already configured, the command erases the configuration. If you accidentally do erase the configuration on a configured system, enter the write memory command to save the running configuration to the startup-config file.
- Page 95 Cautions CAUTION Changes or modifications made to this device that are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. VORSICHT Falls dieses Gerät verändert oder modifiziert wird, ohne die ausdrückliche Genehmigung der für die Einhaltung der Anforderungen verantwortlichen Partei einzuholen, kann dem Benutzer der weitere Betrieb des Gerätes untersagt werden.
-
Page 96: Danger
Danger CAUTION For a DC system (DC power supply part number RPS9-DC), use a grounding wire of at least 6 American Wire Gauge (AWG). The 6 AWG wire should be attached to an agency-approved crimp connector, crimped with the proper tool. VORSICHT Für Geräte mit Gleichstromversorgung (Gleichstromnetzteil, Teilenummer RPS9-DC) muss zur Erdung ein Kabel der Stärke 6 AWG (American Wire Gauge) verwendet werden. - Page 97 Danger WARNING Make sure the rack or cabinet housing the device is adequately secured to prevent it from becoming unstable or falling over. GEFAHR Stellen Sie sicher, dass das Gestell oder der Schrank für die Unterbringung des Geräts auf angemessene Weise gesichert ist, so dass das Gestell oder der Schrank nicht wackeln oder umfallen kann.
- Page 98 Danger WARNING If the installation requires a different power cord than the one supplied with the device, make sure you use a power cord displaying the mark of the safety agency that defines the regulations for power cords in your country. The mark is your assurance that the power cord can be used safely with the device.
- Page 99 Danger WARNING Before beginning the installation, refer to the precautions in“Power precautions” page 30. GEFAHR Vor der Installation siehe Vorsichtsmaßnahmen unter “Power precautions” (Vorsichtsmaßnahmen in Bezug auf elektrische Ablagen) auf den Seiten 30. DANGER Avant de commencer l'installation, consultez les précautions décrites dans “Power precautions”...
- Page 100 Danger Brocade NetIron CES and Brocade NetIron CER Hardware Guide 53-0000080-03...
-
Page 101: Hardware Specifications
Appendix Hardware Specifications This chapter provides the following specifications for the Brocade devices: • “Hardware specifications” • “Port specifications” • “Power cords” Hardware specifications This section contains the following hardware specifications for the Brocade devices: • “Power specifications” • “Physical dimensions” •... -
Page 102: Physical Dimensions
Hardware specifications TABLE 15 Maximum power calculations at 100-240 VAC with two PSUs (Continued) Devices Watts BTUs per hour Brocade NetIron CES 2024F-4X with 4x10G uplink installed Brocade NetIron CES 2024F Brocade NetIron CES 2024F with 2x10G uplink installed Brocade NetIron CES 2048C Brocade NetIron CES 2048CX Brocade NetIron CES 2048F Brocade NetIron CES 2048FX... - Page 103 Hardware specifications TABLE 16 Physical dimensions of the Brocade devices Devices Height Width Depth Weight (fully-loaded) (LB) Brocade NetIron CES 1 RU 17.44 in 17.64 in 15.5 2024C 1.7 inches 44.3 cm 44.8 cm 4.4 cm Brocade NetIron CES 1 RU 17.44 in 17.64 in 17.5...
-
Page 104: Operating Environment
Hardware specifications TABLE 16 Physical dimensions of the Brocade devices Devices Height Width Depth Weight (fully-loaded) (LB) Brocade NetIron CER 1 RU 17.44 in 17.30 in 21.8 2024F-4X-RT with 4x10G 1.7 inches 44.3 cm 43.9 cm uplink installed 4.4 cm Brocade NetIron CER 1 RU 17.44 in... -
Page 105: Safety Agency Approvals
Hardware specifications • Total air flow: 267 LFM • Fan operating noise: • Based on ISO 7779 • < 60 dB-A Safety agency approvals • CAN/CSA-22.2 No.60950-1-07/UL 60950-1-Second Edition • EN 60825-1 Safety of Laser Products – Part 1: Equipment Classification, Requirements and User’s Guide •... -
Page 106: Port Specifications
Port specifications Port specifications This section provides pin assignments for the following ports: • Device’s console port (serial connector) • Device’s management port (RJ-45 unshielded twisted pair (UTP) connector) DANGER The intra-building ports of the equipment or subassembly is suitable for connection to intra-building or unexposed wiring or cabling only. -
Page 107: Management Port Pin Assignments
Port specifications NOTE As indicated in Figure 47 Figure 48, some of the wires should not be connected. If you do connect the wires that are labeled “Reserved”, you might get unexpected results with some terminals. FIGURE 48 Console port pin assignments showing cable connection options to a terminal or PC Management port pin assignments The management port is an RJ-45 UTP connector. -
Page 108: Power Cords
Power cords Power cords The types of power cords provided with the Brocade are specific to the country where they are installed. To order a power cord, contact your Brocade supplier. TABLE 20 Power cord types (international) Country Plug style NEMA 5-15P CEE-7/7 BS-1363A... - Page 109 Power cords TABLE 20 Power cord types (international) (Continued) Country Plug style NEMA 5-15P CEE-7/7 BS-1363A AS 3112 IEC-60309 125V only “Schuko” various Australia/New 16A, 3 wire, USA, Canada, Continental locations Zealand 220-250V Japan, other Europe locations Israel Italy Japan Korea, South Malaysia Alternate...
- Page 110 Power cords TABLE 20 Power cord types (international) (Continued) Country Plug style NEMA 5-15P CEE-7/7 BS-1363A AS 3112 IEC-60309 125V only “Schuko” various Australia/New 16A, 3 wire, USA, Canada, Continental locations Zealand 220-250V Japan, other Europe locations Venezuela Yugoslavia NOTE NEMA 5-15P should only be considered after taking into account the total power consumption on the system.
