2. On the Network Configuration page, enter values for the parameters indicated in
Stored Network Settings
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
VLAN ID (0-4095)
VLAN Priority (0-7)
DHCP Timeout
DHCP Timeout in seconds
Current Network Settings
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
3. You must click on the Save button and then the Reboot button for the changes to take effect.
Operations Guide
Table 2-8. Network Configuration Parameters
Web Page Item
930242A-D
Select either DHCP IP Addressing or Static IP Addressing by
marking the appropriate radio button. If you select Static, configure
the remaining parameters indicated in
go to Step 3.
Enter the Static IP address.
Enter the Subnet Mask address.
Enter the Default Gateway address.
Enter the DNS Server 1 address.
Enter the DNS Server 2 address.
Enter the VLAN ID number.
Note: The device supports 802.11Q VLAN tagging support. The
switch port connected to the device will need to be in "trunking mode"
for the VLAN tags to propagate.
Enter the VLAN priority number.
Enter the desired timeout duration (in seconds) that the device will
wait for a response from the DHCP server before defaulting back to
the stored static IP address.
Note: A value of -1 will cause the device to retry indefinitely and a
value of 0 will cause the device to reset to a default of 60 seconds.
Shows the current network settings.
Shows the current Static IP address.
Shows the current Subnet Mask address.
Shows the current Default Gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Installing the VoIP Intercom
Description
Table 2-8 . If you select DHCP,
CyberData Corporation
34
Intercom Setup
Table 2-8.
