TECDIS Installation Manual
Speaker HP-6/HPS-6:
Material/Color
Mounting
Termination
Weight
IP-rating (UL
Equivalent)
Max. / min. amb.
Temp
Rated / max. power
SPL 1W/1m
SPL rated power
Effective freq. range
Dispersion (-6dB)
1kHz / 4kHz
Directivity factor, Q
Telchart Alarm interface, TEA-01:
Outputs: (connector 1,2,3,4)
are a solid state relay LCA110E which has capabilities of max 50VDC, max 200mA.
Input: (connector 5,6)
uses a current limited (6.8 Kohm resistor) opto coupler MCT5211. Reset in at 10-30 VDC.
All input and outputs are electrically isolated.
Shield shall be connected at alarm central side.
Shield are connected in Dsubmin 9f. connector,
but are not cross connected in the interface box.
A 1.5 m Cable with Dsubmin 9p female (PC-serial port) in one end and an interface box with 7
screw terminal in the other end.
Wiring info:
(1)> Alarm Out - (NO)
(2)> Alarm Out + (NO)
(3)> Sound Alarm out reset - (NO)
(4)> Sound Alarm out reset + (NO)
(5)< Sound Alarm inp. Reset – (NO)
(6)< Sound Alarm inp. Reset + (NO)
(7)- Cable shield
Polyamide UL94 V0 / RAL 7035
90°C / -40 °C
500 – 7500 Hz
Bracket
Cable,0,5m
0.5 kg
(-) 67
6W / 15W
101 db
108 db
170° / 70°
4,3
