TECDIS Installation Manual
Mouse-Trak B-MPIND-XROHS:
Functional Specifications:
Resolution:
Input Switches:
Interface:
Connector:
Pin Assignments:
Compatibility:
Switches:
Cable:
Power Consumption: Idle: 8mA
Mechanical Specifications:
Dimensions:
Weight:
Body Material:
Ball Material:
Ball Hardness:
Tracking Force:
Ball Load:
Ball Speed:
Hand Pad:
Environmental Specifications:
Operating
Temperature:
Storage Temperature: -20 to +60 degrees Celsius
Humidity:
192 to 576 pulses per revolution of the ball.
Three (3)
IBM PS/2
6-Pin Mini-DIN Male
Pin 1 = PS/2 Data
Pin 2 = NC
Pin 3 = Common
Pin 4 = +5V
Pin 5 = PS/2 clock
Pin 6 = NC
Microsoft PS/2 Mouse Protocol, Logitech PS/2 Mouse
Protocol
Mechanically limited, break resistant
96"+-0.5"
Max: 12mA
Approximately 4"wide x 8"long
1.3 lbs.
Glass filled Xenoy thermoplastic, black
Cast Phenolic Resin
Rockwell H 85
1.5 oz. maximum, 0.5 oz. typical (15g)
250 lbs. maximum downward
500 RPM maximum
Injection-molded vinyl, black
0 to +50 degrees Celsius
0 to 95% non condensing
