82
SymDec 4
User Manual
Technical Specifications
General
Power Supply
AC Amps
Operating Temperature Range
Relative Humidity Range (Non-Condensing)
Dimensions
Weight
Connections
Accessory I/O Port
RS-232 Serial Port
Composite Video In
Composite Video Out
Audio In
Audio Out
10/100 Ethernet Port
Video
Video Signal Input
Video Signal Output
Input Termination
Colors
Gray Scale
Horizontal Resolution
Vertical Resolution
Video Compression Standard
Audio Compression Standard
100-240 Volt AC, Auto-Ranging adapter
1.65-0.85 A
Operating: 0 to 40 ºC. Storage: -20 to +60 ºC.
Operating: 10% to 80%. Storage: 10% to 95%
Inches: 3.4 x 8.5 x 15.7, mm: 86 x 216 x 399
9.25 lbs. (4.20 kg)
DB-9 Male. Accessories Port
RJ-45 Connector, 57600 Baud, 8,N,1, No flow control
BNC Connector
BNC Connector
RCA Connector
RCA Connector
RJ-45 Connector
0.7 to 1.4 Volts peak-to-peak, with Automatic Gain Control
1 Volt peak-to-peak into 75-ohm
75-ohm
Y:U:V 4:2:2, 16.8 Million Colors
256 Levels
720 Pixels
484 Lines
MPEG4
MPEG1 Layer 2
