Starting VSR Keyboard

To start the VSR Keyboard program, double-click on the VSR Keyboard desktop icon
Programs from the Start menu and then select VSR Keyboard. The Main window of the VSR Keyboard
program will appear.
Figure 6. VSR Keyboard buttons
This program acts as a virtual front panel for the SymDec 4. The following describes each of the controls and a
brief description of their function.
1. Analog Camera Buttons 1-4: Selects an analog camera to display on monitor A.
2. Digital Camera Buttons 1: Selects the digital camera to display on monitor A.
3. Record Speed Buttons: Increases or decreases the recording speed.
4. Record Button: Click to begin or stop recording.
5. Pause Button: Click to pause recording.
6. Search Button: Click to launch search interface.
7. Menu Button and Playback control cluster: These buttons are used for playback control (fast
forward, rewind) and menu access and navigation.
8. Enter Button: Used to select and confirm menu item selections.
9. 4-way Multiscreen: Used to select a 4-way multiscreen on monitor A.
10. Alarm Button: Used to silence audible alarms. It does not turn off the alarm condition.
11. Sequence Button: Use this button to sequence through all camera displays.
12. Reverse Play Button: Runs playback in reverse.
13. Stop Button: Stops playback and returns to live mode.
14. Play Forward Button: Begins playback.
15. Power Indicator: Indicates power on/off condition (Ethernet connection only).
16. File Menu: Has various drop-down menus for the configuration of the program.
15
or choose
