70
SymDec 4
User Manual
Use thus menu to specify:
•
The data transfer rate for the RS-232 serial port.
•
Configure the network address for the RS485 network.
•
The units Ethernet network connection settings.
•
Configure the User Datagram Protocols (UDP) to broadcast and receive data.
Advanced Menu / Communications / Baud Rate
Figure 79. The baud rate selection menu
Use the Arrow buttons to select the Baud Rate.
click the Enter button to confirm the selection and exit the menu, or click the Menu button to exit the menu
without making changes.
Advanced Menu / Communications / RS485
Figure 80. The network address menu
Use this menu to specify the units unique network address.
Save changes and exit the menu: click the Enter button.
Exit the menu without making changes: click the Menu button.
Advanced Menu / Communications / Ethernet Settings
An Ethernet session is an active network connection between a PC and the unit, with the user viewing live
camera images or accessing data stored on the hard disk.
