Advantech MT-100 User Manual

Advantech MT-100 User Manual

Amd lx800 m processor-based point of care terminal with 10.4 tft lcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Tablet-PC
AMD LX800® M processor-based
Point of Care Terminal with 10.4" TFT
LCD
User's Manual
1/61
MT-100 Tablet PC User Manual

Advertisement

Table of Contents
loading

Related Manuals for Advantech MT-100

Summary of Contents for Advantech MT-100

  • Page 1 Tablet-PC AMD LX800® M processor-based Point of Care Terminal with 10.4” TFT User’s Manual 1/61 MT-100 Tablet PC User Manual...

  • Page 2: Fcc Class B

    -- Battery Pack x1 + screws for Battery -- User's manual & "Drivers and Utilities" in CD-ROM disc -- Touch Pen x1 Figure 1.0 MT-100 and Accessories Warning To prevent electric shock, Do not remove cover. No user serviceable parts inside, refer servicing to qualified personnel.

  • Page 3: Additional Information And Assistance

    1. Visit the Advantech websites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information...
  • Page 4 27. The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70dB (A). DISCLAIMER This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein 4/61...
  • Page 5 This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems. Stand-by Direct Current 5/61 MT-100 Tablet PC User Manual...

  • Page 6: Chapter 1General Information

    Audio Integrated speakerx1, Microphone x1 Model: MT-BATE Power Battery Removable 11.1V@4800mAh Li-ion battery pack support warm swappable 10% Low battery Alarm 6% Critical low Discharge Time 3 hours battery life Charging Time 3.5 hours 6/61 MT-100 Tablet PC User Manual...

  • Page 7: Lcd Panel Specifications

    Option Modules Digital camera 1.3M Camera Module Bluetooth USB x4, RS-232x1, LAN x1, VGA x1, Smart card MT-CRADLE readerx1 Table 1.1: MT-100 Tablet specification 1.2 LCD Panel Specifications LCD model (MT-100-AE) AU G104SN03 Display type TFT color LCD Size (Diagonal) 10.4”...

  • Page 8: Touchscreen Specifications

    Do not spray cleaning agent on the chassis. Do not use disinfectants that contain phenol. Do not autoclave or clean the MT-100 or its peripherals with strong aromatic, chlorinated, ketone, ether, or Esther solvents, sharp tools or abrasives. Never immerse electrical connectors in water or other liquids.
  • Page 9 This device bears the CE label in accordance with the provisions of the EMC Directive 89/336/EMC and the Low Voltage Directive 73/23/EEC. Agency CE, FCC approved Approvals UL60601-1 and EN60601-1 approved. Safety Table 1.5: MT-CRADLE specification 9/61 MT-100 Tablet PC User Manual...
  • Page 10 Dimensions :266.4 x 211.4 x 36 mm ; VESA mount 75 x75mm Figure 1-1: Dimensions of the Tablet PC Dimensions : 217.4 x 156.8 x 42.4 mm ; VESA mount 75 x75 mm Figure 1-2: Dimensions of the CRADLE (Optional) 10/61 MT-100 Tablet PC User Manual...

  • Page 11: Chapter 2 System Setup

    Power ON Switch Speaker USB Port Figure 2-2: Left side view of the Tablet PC When you look at the right side of the panel PC, you will see the USB port. Figure 2-3. 11/61 MT-100 Tablet PC User Manual...
  • Page 12 When you turn the Tablet PC around and look at its rear cover. Figure 2-4. Rating Label Battery Pack (for Engineer only) HDD Door For Maintain only Figure 2-4: Rear view of the Tablet PC 12/61 MT-100 Tablet PC User Manual...
  • Page 13 When you place the CRADLE upright on the desktop, its front panel appears as shown in Figure 2-5. Figure 2-5: Front View of the CRADLE When you turn the CRADLE around and look at its rear cover. Figure 2-6. Button Switch Figure 2-6: Rear View of the CRADLE 13/61 MT-100 Tablet PC User Manual...

  • Page 14: Installation Procedures

    Do not attempt to replace the battery with any others than the models recommended and manufactured specifically for this tablet PC. Note! Before using MY-100 Tablet PC, please connect the adapter into MT-100 to charge the battery and backup battery at least 24Hrs. 2.2.1.1 Installing a Battery The battery is designed specifically for installation with the MT-100 tablet PC.
  • Page 15 5. Push up the battery pack to close connection with system. Figure 2-8: Push up the battery pack to close Fasten the two battery cover screws. Figure 2-9: Replacing the battery cover screws 15/61 MT-100 Tablet PC User Manual...
  • Page 16 3. Connect the 3-pin male plug of the power cord to an electrical outlet. 4. Open the power switch on AC Adapter. DC Power Inlet Docking Port for CRADLE Power Switch of AC adapter Figure 2-5: Connecting the AC Adapter power supplier with Tablet 16/61 MT-100 Tablet PC User Manual...
  • Page 17 3. Connect the 3-pin male plug of the power cord to an electrical outlet. 4. Open the power switch on AC Adapter. Power Switch of AC adapter Figure 2-6: Connecting the AC Adapter power supplier with CRADLE 17/61 MT-100 Tablet PC User Manual...

  • Page 18: Connecting The Keyboard And Mouse

    2.2.4 Connecting the keyboard and mouse Connect the USB port to the USB mouse and keyboard port on the I/O section of the Tablet PC. (See Figure 2-7.) Figure 2-7: Connecting the Keyboard or Mouse 18/61 MT-100 Tablet PC User Manual...
  • Page 19 3. The Tablet PC must vertical landing to CRADLE (See Figure 2-8.) 4. The button on up of CRADLE down and switch off then Tablet PC can vertical takeoff CRADLE . (See Figure 2-8) Figure 2-8: Combining with CRADLE 19/61 MT-100 Tablet PC User Manual...

  • Page 20: Left Side

    Figure 2-9: Top down view of CRADLE 2.2.6 Switching on the power Switch on the power switch on the left side. Press the power switch button over 0.5 sec then can power on the system. 20/61 MT-100 Tablet PC User Manual...

  • Page 21: Led Signals

    2.3 LED Signals The MT-100 is equipment with a set of Light Emitting Diodes(LEDs) located along the right top of the front Bezel. Power ON/OFF LED Battery Status LED 2.3.1 Power ON/OFF LED Dark : No DC-in from AC adapter Static Green : DC-in from AC adapter Blinking Green: System is in standby mode with AC Adapter DC-in.
  • Page 22 Do not touch the metal pin of Docking by finger, conductivity material , and liquid. The user not to touch the any connectors of the apparatus and the patient simultaneously. It will lead the system crash. 22/61 MT-100 Tablet PC User Manual...
  • Page 23 The keyboard button function can enable On-Screen Keyboard utility. 2.4.4 Display rotation button The rotation button function is the hotkey for rotating the display on screen. 2.4.5 Touch ON/OFF button The Touch button function is the hotkey for touch screen enable/disable function. 23/61 MT-100 Tablet PC User Manual...

  • Page 24: Running The Bios Setup Program

    If you are presented with the opening screen of a setup or installation program, follow the instructions on screen. The setup program will guide you through preparation of your hard drive, and installation of the operating system. 24/61 MT-100 Tablet PC User Manual...

  • Page 25: Installing The Drivers

    Figure 2-5: The file directory on "Drivers and Utilities" CD-ROM Note The drivers and utilities used for the MT-100 panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities.

  • Page 26: Chapter 3 Graphic Chipset Setup

    140MHz, and support 18-bit/24-bit LCD panels. 3.1.4 Display types CRT and panel displays can be used simultaneously. The MT-100 can be set in one of three configurations: CRT only, LVDS only, both CRT and LFP (LVDS). The system is initially set to simultaneous display mode - CRT and LFP (BIOS default setting).

  • Page 27: Installation Of Chipset Driver

    Complete the following steps to install the chipset driver. Follow the procedures in the flow chart that apply to the operating system that you are using within your MT-100. Step 1-1 Click the 'Start' button in the task bar, click 'Control Panel', click 'System' then show a dialogue windows of System Properties.
  • Page 28 Step 1-3 Click the Circle of ‘Yes, this time only ‘ then Click ‘Next’ step. Please Click the Circle of ‘Install from a list or specific location (Advanced). Step 1-4 Click the ‘Include this location in the search’. Then Browse the direction of D:\CHIPSET\AES’ then Click ‘Next’. 28/61 MT-100 Tablet PC User Manual...
  • Page 29 Step 1-5 The system will auto install the Chipset drive as below window. Step 1-6 Please direct to ‘D:\CHIPSET\AES’ then Click ‘OK’ if need more information for installation. 29/61 MT-100 Tablet PC User Manual...
  • Page 30 Note2 <Enter> means pressing the “Enter” key on the keyboard. Note3 Before you install the graphic driver of MT-100, please ensure you have installed the “AMD Chipset Software Installation Utility”. You can find this driver in the Utility CD-ROM. Note4 The resolution of window display will be fix on 640 x 480 before you install VGA driver.

  • Page 31: Installation Of Graphic Driver

    Complete the following steps to install the SVGA driver. Follow the procedures in the flow chart that apply to the operating system that you are using within your MT-100. Step 1-1 Click the 'Start' button in the task bar, click 'Control Panel', click 'System' then show a dialogue windows of System Properties.
  • Page 32 Step 1-3 Click the Circle of ‘Yes, this time only ‘ then Click ‘Next’ step. Please Click the Circle of ‘Install from a list or specific location (Advanced). Step 1-4 Click the ‘Include this location in the search’. Then Browse the direction of ‘D:\VGA\GeodeLX_XP_XPe_Graphics _v3.03.06’ then Click ‘Next’. 32/61 MT-100 Tablet PC User Manual...
  • Page 33 Step 1-5 The system will auto install the Chipset drive as below window. Step 1-6 Please select ‘Continue Anyway’. 33/61 MT-100 Tablet PC User Manual...
  • Page 34 Step 1-7 System automatic to install the VGA drive as below window. Step 1-8 Please direct to ‘D:\VGA\GeodeLX_XP_XPe_Graphics _v3.03.06’ then Click ‘OK’ if need more information for installation. 34/61 MT-100 Tablet PC User Manual...
  • Page 35 Note2 <Enter> means pressing the “Enter” key on the keyboard. Note3 Before you install the graphic driver of MT-100, please ensure you have installed the “AMD Chipset Software Installation Utility”. You can find this driver in the Utility CD-ROM. Note4 The resolution of window display will be fix on 640 x 480 before you install VGA driver.

  • Page 36: Installation Of Audio Driver

    3.4 Installation of Audio Driver Complete the following steps to install the Audio driver. Follow the procedures in the flow chart that apply to the operating system that you are using within your MT-100. Important The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which appear on your screen.
  • Page 37 Controller’. Appear a New dialog then Click the ‘Driver’, Select ‘Update Driver’ will show as below dialog. Step 1-3 Click the Circle of ‘Yes, this time only ‘ then Click ‘Next’ step. Please Click the Circle of ‘Install from a list or specific location (Advanced). 37/61 MT-100 Tablet PC User Manual...
  • Page 38 Step 1-4 Click the ‘Include this location in the search’. Then Browse the direction of ‘D:\AUDIO\Audio’ then Click ‘Next’. Step 1-5 System will automatic to install the Chipset drive as below window. 38/61 MT-100 Tablet PC User Manual...
  • Page 39 Step 1-6 Please select ‘Continue Anyway’. Step 1-7 Please direct to ‘D:\AUDIO\Audio’ then Click ‘OK’ if need more information for installation. 39/61 MT-100 Tablet PC User Manual...
  • Page 40 Step 1-8 System will continuing install the Chipset drive as below window. Step 1-9 When appear the ‘Completing the Hardware update Wizard’ dialog then can Click the ’Finish’ button to complete it. 40/61 MT-100 Tablet PC User Manual...

  • Page 41: Further Information

    3.4.1 Further information For further information about the CHIPSET, VGA , AUDIO installation in your MT-100, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. AMD website: www.AMD.com Advantech websites: www.advantech.com 41/61 MT-100 Tablet PC User Manual...

  • Page 42: Chapter 4 Touch Screen Interface

    4.1 Introduction 4.1.1 General Information The MT-100's optional touch screen incorporates advanced second-generation 5-wire resistive technology. They allow 75% light transmission respectively. The resistive and capacitive models have an antiglare surface. All models provide greatly enhanced visual resolution. They also have new improved scratch-resistant features.

  • Page 43: Installation For Windows 2000/Xp

    4.2.1 Installation for Windows 2000/XP 4.3 Further information For further information about the Touchscreen installation in your MT-100, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. ELO website: http://www.elotouch.com/ EETI website: http://www.eeti.com.tw/ Advantech websites: www.advantech.com...

  • Page 44: Chapter 5 Hotkey Function Application

    5.1 Introduction 5.1.1 General Information The MT-100's features a build in Wireless Ethernet card by MiniPCI interface. Free cable when you surfing web screen, Display rotation and T/S on/off button. There Hotkey can customize if customer have request for it.
  • Page 45 Step 1-2 Wait for the AP automatic install. Step 1-3 Press the “Next” when show the window. 45/61 MT-100 Tablet PC User Manual...
  • Page 46 Step 1-4 Please select the “ I accept the term of the license agreement” then press ”Next”. Step 1-5 AP will keep going to implement it. 46/61 MT-100 Tablet PC User Manual...
  • Page 47 Step 1-6 Press the “Finish” button when show the Complete window. 47/61 MT-100 Tablet PC User Manual...

  • Page 48: Chapter 6 Wlan Driver Installation

    Chapter 6 WLAN driver installation 6.1 Introduction 6.1.1 General Information Step 1-1 Click the ‘Include this location in the search’. Then Browse the direction of ‘D:\WLAN\ 080229_RT61_D_1.2.3.0_VA_2.1.0.0_RaUI_2.0.7.0_VA_2.0.9.0_for 2K&XPx86 VAx86’ then double Click it. 48/61 MT-100 Tablet PC User Manual...
  • Page 49 Step 1-2 The WLAN drivers will auto download file then show the License window. Please select the “ I accept the term of the license agreement” then press ”Next”. Step 1-3 Select the “Ralink Corporation Tool” then Press ‘Next’. 49/61 MT-100 Tablet PC User Manual...
  • Page 50 Step 1-4 Select the ‘Optimize WiFi mode’ then Press ‘Next’. Step 1-5 Select the ‘Install’ 50/61 MT-100 Tablet PC User Manual...
  • Page 51 Step 1-5 Auto install driver Step 1-6 Driver implement complete, Please press the ‘Finish’ button. 51/61 MT-100 Tablet PC User Manual...
  • Page 52 Step 1-7 Ralink WLAN utility user interface . 6.1 Further information For further information about the WLAN card installation in your MT-100, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. RaLink website: http://www.Ralink.com.tw/ Advantech websites: www.advantech.com...

  • Page 53: Chapter 7 Mt-Cradle Drivers Installation

    7.1 Introduction 7.1.1 General Information MT-CRADLE is MT-100 tablet PC series option Docking station. It is include multi I/O port for more application. These I/O port include USB x 4 ports, RS-232 Port x1, Gigabit LAN port x1, VGA port and Smart Card Reader. We must install drivers for these add on I/O ports then by be 1.
  • Page 54 7.2. USB to LAN driver installation Step 1-1 When you setup the cradle and plug the power in with adapter. The MT-100 tablet PC connect with CRADLE. The SYSTEM will auto detect “Found New Hardware” . The show the “Files needed” windows. Please press the “Browse” .
  • Page 55 Step 1-2 Then Browse the direction of ‘D:\USB-LAN\ F:\AX88772_772A_WinXP2K_32bit_v3.4.3.18_WHQL’ will show the AX88772.sys file. Select it and press the “Open” Button. Step 1-3 Please press the “OK” Button then auto implement the drivers. 55/61 MT-100 Tablet PC User Manual...
  • Page 56 Step 1-4 You can double check after install driver on Device manager. As below red line the driver is available on system. 56/61 MT-100 Tablet PC User Manual...

  • Page 57: Usb To Rs-232 Driver Installation

    “PL-2303 Driver Installer” file. Then double clock it. Step 1-2 The driver will auto install it. Please select “Yes, I want to reboot computer now” and press the “Finish’ button. System will re-boot. The driver is available. 57/61 MT-100 Tablet PC User Manual...
  • Page 58 Note1 The CD-ROM drive is designated as “D” throughout this chapter. Note2 <Enter> means pressing the “Enter” key on the keyboard. 58/61 MT-100 Tablet PC User Manual...
  • Page 59 Step 1-1 Click the ‘Include this location in the search’. Then Browse the direction of ‘D:\Smart Card Reader\ACR’ then double Click ‘Setup’. Step 1-2 Wait for the AP automatic install. 59/61 MT-100 Tablet PC User Manual...
  • Page 60 Step 1-3 Please select the “Yes” button to continue installation. Step 1-4 Please express the “Finish” button when show the screen. Complete driver installation. 60/61 MT-100 Tablet PC User Manual...
  • Page 61 7.4.3 Further informatio For further information about the Smart card reader installation in your MT-100, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. The model is ACR38. ACS website: http://www.ACS.com.hk Advantech websites: www.advantech.com 61/61...
