  • Page 1 User Manual TREK-722/723 RISC All-In-One Mobile Data Terminal...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    20cm (8 inches) during normal operation. Changes or modifications not expressly approved by the party responsible for com- pliance could void the user’s authority to operate the equipment. TREK-722/723 User Manual...

  • Page 4: Packing List

    Technical Support and Assistance Visit the Advantech web site at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 5: Safety Instructions

    The equipment has been exposed to moisture.  The equipment does not work well, or you cannot get it to work according to the user's manual.  The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. TREK-722/723 User Manual...
  • Page 6 Transport: carry the unit with both hands and handle with care. Maintenance: to properly maintain and clean the surfaces, use only approved products or clean with a dry applicator. SD/SIM card: Turn off the power before inserting or removing the storage cards. TREK-722/723 User Manual...

  • Page 7: Table Of Contents

    Figure 1.2 TREK-723 dimensions..........4 Chapter System Setup ........5 A Quick Tour of the TREK-722/723 Mobile Data Terminal ....... 6 Figure 2.1 Front view of TREK-722/723 ........6 Figure 2.2 Rear view of TREK-722/723........6 Figure 2.3 Bottom view of TREK-722/723 ........6 Installation Procedures................
  • Page 8 How to install SDK ..............35 5.7.4 Running IMC SDK CE Demo Test..........39 5.7.5 Running your application programs ..........44 5.7.6 SUSI library for application program........... 44 Windows® Embedded CE 6.0 Component List ........44 TREK-722/723 User Manual viii...

  • Page 9: Chapter 1 General Information

    Chapter General Information This chapter gives background information on the TREK-722/723 Mobile Data Terminal. Sections include:  Introduction  General Specifications  Dimensions...

  • Page 10: Introduction

    Operating temperature: -20 ~ 60° C (5") & -30 ~ 70° C (7")  Storage temperature: -30 ~ 80° C Specifications  Dimensions: 165 x 115 x 43 mm (TREK-722) / 213 x 145 x 43 mm (TREK-723)  Weight: 650 gram (TREK-722) / 850 gram (TREK-723)  Power feature: –...
  • Page 11 Operating Temperature: -20° C ~ 60° C & -30 ~ 70° C (7") – Relative Humidity: 10 ~ 90% @ 40° C (non-condensing) – Shock/Vibration: MIL-STD-810G, SAE J1455, Class 5M3 according DIN EN 60721-3-5 – Certificate: CE, FCC, CCC, UL, CUL, CB, E-mark TREK-722/723 User Manual...

  • Page 12: Dimensions

    1.3 Dimensions 164.70 Unit: mm Figure 1.1 TREK-722 dimensions 212.70 Unit: mm Figure 1.2 TREK-723 dimensions TREK-722/723 User Manual...

  • Page 13: Chapter 2 System Setup

    Chapter System Setup This chapter details system setup on TREK-722/723. Sections include:  A Quick Tour of the Mobile Data Terminal  Installation Procedures  WinCE Satrtup Procedure...

  • Page 14: A Quick Tour Of The Trek-722/723 Mobile Data Terminal

    2.1 A Quick Tour of the TREK-722/723 Mobile Data Terminal Before starting to set up the Mobile Data Terminal, take a moment to become familiar with the locations and functions of the controls, drives, connectors and ports, which are illustrated in the figures below. When the Mobile Data Terminal is placed inside truck glove cabinet or under the passenger’s seat next to the driver, its front appears...

  • Page 15: Installation Procedures

    2.2 Installation Procedures When you installing TREK-722/723, the first step will be connect the power and igni- tion correctly. TREK-722/723 power cable is designed to connect battery directly. TREK-722/723 can be switched ON/OFF by the ignition signal or its power button both.
  • Page 16 TREK-722/723 User Manual...

  • Page 17: Chapter 3 Hardware & Peripheral Installation

    Chapter Hardware & Peripheral Installation This chapter details the installa- tion of hardware for TREK-722/ 723. Sections include:  Installing the Storage Device and SIM Card  Installing Optional Accessories...

  • Page 18: Installing The Storage Device And Sim Card

    3.1 Installing the Storage Device and SIM Card Users can install SIM card and storages (SD card) easily on TREK-722. SD card is the main bootable storage which has OS pre-installed from Advantech. 3.2 Installing Optional Accessories Optional accessories, like RAM mount kits (RAM-MOUNT-02, RAM-MOUNT-07E) or other functional modules are available for purchase to complement TREK-722/723.

  • Page 19: Installing Standard Wireless Options

    WWAN, Bluetooth and GPS modules are already installed inside of unit. 3.3.1 WWAN (Internal Antenna) Position of internal WWAN antenna is shown as below blue area: 3.3.2 Bluetooth (Internal Antenna) Position of internal Bluetooth antenna is shown as below blue area: TREK-722/723 User Manual...

  • Page 20: Gps (Internal Antenna)

    3.3.3 GPS (Internal Antenna) Position of internal Bluetooth antenna is shown as below blue area: Note! While installing TREK-722/723, make sure the surrounding doesn't block the blue area for optimal WWAN, Bluetooth and GPS perfor- mance. 3.4 Installing External Wireless Antenna Options 3.4.1 HSPA and GPRS (External Antenna)

  • Page 21: Cdma (External Antenna)

    Install WWAN antenna to below output. 3.4.2 CDMA (External Antenna) Make sure CDMA Module (MC5728) and SMA cable have been installed in TREK-722/723. Install WWAN antenna to below output. TREK-722/723 User Manual...

  • Page 22: Gps (External Antenna)

    3.4.3 GPS (External Antenna) Make sure GPS Module (b-blox LEA-6S) and SMA cable have been installed in TREK-722/723. Install GPS antenna to below output. TREK-722/723 User Manual...

  • Page 23: Chapter 4 Pin Assignments

    Chapter Pin Assignments This chapter explains pin assign- ments on the TREK-722/723.

  • Page 24: Rear Side Connectors

    4.1 Rear Side Connectors In order to access SD connector, USB Client (mini-B connector) and USB Host (USB A-type connector), please open the rubber door on the right side of TREK-722/723. TREK-722/723 User Manual...

  • Page 25: Extended Io

    Signal USB_G USB_5V USB_G USB_5V TX-A USB_DP RTS-A USB_DM RX-A ISOD_GND CTS-A TX-B RTS-B DI-1_N RX-B DI-1_L CTS-B DI-2_N DGND DI-2_L DGND MIC-LINE_IN J1850_P AUDIO_GND J1850_N LINE-OUT_R CAN-H AUDIO_GND CAN-L LINE-OUT_L ISO-L VIDEO_GND ISO-K VIDEO_GND VIDEO_GND CVBS TREK-722/723 User Manual...

  • Page 26: Hdc Cable Connectors (Optional) (Advantech P/N: 1700020042)

    4.3 HDC Cable Connectors (Optional) (Advantech P/ N: 1700020042) TREK-722/723 User Manual...
  • Page 27 TREK-722/723 User Manual...
  • Page 28 TREK-722/723 User Manual...
  • Page 29 TREK-722/723 User Manual...
  • Page 30 TREK-722/723 User Manual...

  • Page 31: Chapter 5 Software Functionality

    Chapter Software Functionality This chapter details the Win- dows® 6.0 operating system on the TREK72x platform. Sections include:  Introduction  Windows® CE Startup Proce- dure  Upgrade Procedure  Utilities  Network  Application Program Develop- ment  Windows® Embedded CE 6.0 Require Components...

  • Page 32: Introduction

    Windows CE image inside, BOOTLOADER will load the Windows CE image from on-board system flash chip. BOOTLOADER copy Win- dows CE image to DRAM and launch WinCE from DRAM, whenever loaded by exter- nal storage card or system on-board flash chip. TREK-722/723 User Manual...

  • Page 33: Upgrade Procedure

    5.3 Upgrade Procedure Advantech release three files for TREK72x platform. MLO&EBOOT.NB0 is boot- loader and NK.BIN is WinCE6.0 image. 5.3.1 Prepare SD card for bootloader a) Disk format with HPUSBFW.EXE. Figure 5.2 Storage format tool b) Copy file for upgrade image: Copy MLO to sd card for TI CPU boot code.

  • Page 34: Figure 5.4 Upgrade Finish

    Format disk with wince tools Storage Manager on the Control panel like Figure 5.4. Copy files to Storage card that include MLO/EbootSD.nb0/NK.bin but MLO must be copied first. Relation files on the "Image" folder like a) Auto Upgrade. Figure 5.5 Format disk TREK-722/723 User Manual...

  • Page 35: Utilities

    Also, you can remove test items from right zone by pressing "Remove" button. After you add test items done, you can go function test by pressing "EXE ALL" but- ton. To press "View Rpt" button, you will see the test result. Figure 5.6 Test Utility TREK-722/723 User Manual...

  • Page 36: Startup Execution

    5.4.4 Platform Setting Platform Setting utility is an outstanding utility designed by Advantech Windows? CE software team. It is an integrated environment where user can get useful system information as well as configure favorite system settings and apply system control function on demand.

  • Page 37: Figure 5.7 General Information

    Figure 5.7 General information 5.4.4.2 Audio The Audio page is setting recorder that include "Microphone" and "Line In". The record function default select is "Line In". Figure 5.8 Audio TREK-722/723 User Manual...

  • Page 38: Network

    Connections". User can configure its 3G support as follows: a) Manual Click "Start/Settings/Control Panel" Double click "Network and Dial-up Connections" If the TREK72x is a node of the LAN with 3G servers, it is now available. Support Module have Tc63i/PH8/SierraWireless Figure 5.9 3G via Ethernet TREK-722/723 User Manual...

  • Page 39: Figure 5.10Rf Module Manager

    Next select item "auto connect" is dial up every condition of disconnect automatically. Figure 5.10 RF module manager Note! In order to fit every area to connect ISP(Internet Service Provider) must change content of "Extra Settings" like Figure 5.11. Figure 5.11 ISP modern setting TREK-722/723 User Manual...

  • Page 40: Example For Verizon Cdma Setup

    5.5.2 Example for Verizon CDMA Setup On the next screen set the phone number to “#777” and click finish. Double click on the Verizon icon. Tap the dial properties, and use the drop down to select “CAR” and tap OK. TREK-722/723 User Manual...
  • Page 41 The next window will say “Dialing #777” If everything is OK, after a short time, you will hear a connect sound, and the Verizon status window will say “Connected” Note! Fill in the “extra settings” field. Picture below for reference. TREK-722/723 User Manual...

  • Page 42: Touch Calibration

     200MB free hard disk space at least  TREK72x platform  Let the host PC and TREK72x connect on the same USB1.1 to do kernel debugging if necessary  USB cable (bundled in the standard TREK72x) TREK-722/723 User Manual...

  • Page 43: Building Windows Ce Program

    Figure 5.13 Flow-chart of Building Windows® Embedded CE 6.0 runtime 5.7.3 How to install SDK For example copy Platform SDK file "**.msi" to your PC, and launch it. You can install SDK by steps. Launch Platform SDK file, and then tap Next button. TREK-722/723 User Manual...
  • Page 44 Accept License Agreement and go next. Key in your information and go next. TREK-722/723 User Manual...
  • Page 45 Choose setup type. TREK-722/723 User Manual...
  • Page 46 Tap "Install" button to install SDK. Install SDK..Finish installing. TREK-722/723 User Manual...

  • Page 47: Running Imc Sdk Ce Demo Test

    To access Core Function Test, click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_CORE_FUNCTION/ TREK_722_Sample_Code_CORE_FUNCTION/obj/Debug and execute TREK_722_Sample_Code_CORE_FUNCTION.exe 5.7.4.2 DIO Test To access DIO Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_DIO/ TREK_722_Sample_Code_DIO/obj/Debug and execute TREK_722_Sample_Code_DIO.exe 5.7.4.3 Display Test To access Display Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_DISPLAY/ TREK_722_Sample_Code_DISPLAY/obj/Debug and execute TREK_722_Sample_Code_DISPLAY.exe TREK-722/723 User Manual...
  • Page 48 5.7.4.4 Hotkey Test To access Hotkey Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_Hot_key/ TREK_722_Sample_Code_Hot_key/obj/Debug and execute TREK_722_Sample_Code_Hot_key.exe 5.7.4.5 I C Test To access I C Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_IIC/ TREK_722_Sample_Code_IIC/obj/Debug and excute TREK_722_Sample_Code_IIC.exe TREK-722/723 User Manual...
  • Page 49 5.7.4.6 Light Sensor Test To access Light Sensor Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_Light_Sensor/ TREK_722_Sample_Code_Light_Sensor/obj/Debug and execute TREK_722_Sample_Code_Light_Sensor.exe 5.7.4.7 Peripheral Control Test To access Peripheral Control Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_PeripheralCtrl/ TREK_722_Sample_Code_PeripheralCtrl/obj/Debug and execute TREK_722_Sample_Code_PeripheralCtrl.exe TREK-722/723 User Manual...
  • Page 50 5.7.4.8 VPM Test To access VPM Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_VPM/ TREK_722_Sample_Code_VPM/obj/Debug and execute TREK_722_Sample_Code_VPM.exe 5.7.4.9 Watch Dog Test To access Watch Dog Test, please click "IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_Watch_Dog/ TREK_722_Sample_Code_Watch_Dog/obj/Debug" and execute TREK_722_Sample_Code_Watch_Dog.exe TREK-722/723 User Manual...
  • Page 51 5.7.4.10 CAN Bus Test To access CAN Bus test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_CAN/ TREK_722_Sample_Code_CAN/obj/Debug and execute TREK_722_Sample_Code_CAN.exe 5.7.4.11 J1939 Test To access J1939 Test, please click IMC_SDK_V2/sample/CE/TREK_722_Sample_Code_J1939/ TREK_722_Sample_Code_J1939/obj/Debug and execute TREK_722_Sample_Code_J1939.exe TREK-722/723 User Manual...

  • Page 52: Running Your Application Programs

    5.7.5 Running your application programs After you implement application code, you should choose Advantech SDK to com- pile. 5.7.6 SUSI library for application program TREK72x is targeted to be the embedded device for system integrator. System inte- grator usually access platform relative IO, like backlight control, brightness control, etc.
  • Page 53 XML HTTP XML Query Languages (XQL) XML Stylesheet Language Transformations (XSLT) XML SAX XML Error Strings XML Minimal Parser Exchange Client APPLICATIONS - END USER ActiveSync File Sync Inbox Sync Pocket Outlook Database Sync CAB File Installer/Uninstaller TREK-722/723 User Manual...
  • Page 54 USB Remote NDIS Class Driver Debugging Tools Keyboard Test Application Touch Driver Test Application Remote Display Application Tiny Kernel Test Sample Application Toolhelp API LMemDebug Memory Debugging Hooks x Notification (Choose 1) UI based Notification Non UI based Notification TREK-722/723 User Manual...
  • Page 55 AV Renderer Sample USB Flash Config Tool Windows Networking API/Redirector (SMB/CIFS) Winsock Support Networking - Local Area Network (LAN) Native Wi-Fi WLAN Access Point Com- ponents Native Wi-Fi WLAN STA Wired Local Area Network (802.3, 802.5) x TREK-722/723 User Manual...
  • Page 56 Core Server Support FTP Server File Server File Server Customizable UI Windows Peer-to-Peer Networking Peer Name Resolution Protocol (PNRP) Identity Manager Print Server RAS Server/PPTP Server (Incoming) Telnet Server Web Server (HTTPD) Active Server Pages (ASP) Support JScript 5.6 TREK-722/723 User Manual...
  • Page 57 Arial (Subset 1_30) Arial Black Arial Bold Arial Bold Italic Arial Italic Comic Sans MS Comic Sans MS Comic Sans MS Bold Courier New Courier New (Subset 1_30) Courier New Bold Courier New Bold Italic Courier New Italic Georgia TREK-722/723 User Manual...
  • Page 58 Tahoma Bold (subset 1_08) Arial (subset 1_08) Arial Bold (subset 1_08) Courier New (subset 1_08) Keyboard Arabic Keyboard (101) Chinese (Simplified) Agfa AC3 Font Compression Fonts SimSun & NSimSun (Choose 1) SimSun & NSimSun SimSun & NSimSun (Subset 2_20) TREK-722/723 User Manual...
  • Page 59 Pocket IME Input Methods Input by Radical (Chang Jei) Handwriting Recognizer Engine (HWX) MboxCHT HWX Sample UI Phonetic Input (Bopomofo) English (Worldwide) Input Methods Handwriting Recognizer Engine (HWX) English (U.S.) Input Methods Transcriber Handwriting Recogni- tion Application French TREK-722/723 User Manual...
  • Page 60 Hindi Traditional Keyboard Marathi Fonts Mangal Keyboard Marathi Keyboard Punjabi Fonts Raavi Keyboard Punjabi Keyboard Telugu Fonts Gautami Keyboard Telugu Keyboard Gujarati Fonts Shruti Keyboard Gujarati Keyboard Kannada Fonts Tunga Keyboard Kannada Keyboard Tamil Fonts Latha Keyboard Tamil Keyboard TREK-722/723 User Manual...
  • Page 61 (HWX) Character Auto Com plete -HWX Sample UI Multibox HWX Sample UI Kana Soft Keyboard Romaji/English Soft Keyboard Search by Radical Search by Stroke Korean Agfa AC3 Font Compression Fonts Gulim (GL_CE) Gulim & GulimChe (Choose 1) TREK-722/723 User Manual...
  • Page 62 Base API Internet Explorer Multiple-Language Full API Optional Charset/Encoding in registry Internet Explorer RPC Support Internet Explorer TV-Style Navigation Fixed-Width Layout Directional Tabbing Disable Vertical Scroll Bar and Events Customizable Font Range URL Moniker Services Windows Internet Services TREK-722/723 User Manual...
  • Page 63 Audio Audio Compression Manager GSM 6.10 Codec MSFilter Codec Waveform Audio Media Streaming Media Playback (requires WMP application) WMA and MP3 Local Playback WMA and MP3 Streaming (requires WMP application) Digital Rights Management Digital Rights Management (DRM) TREK-722/723 User Manual...
  • Page 64 ASX v2 File Support ASX v3 File Support Windows Media Multicast and Multi-Bit Rate NSC File Support Windows Media Streaming from Local Storage Windows Media Streaming over HTTP Windows Media Streaming over SECURITY Authentication Services (SSPI) NTLM TREK-722/723 User Manual...
  • Page 65 Software-based Input Panel (SIP) (Choose 1 or more) SIP for Small Screens SIP for Large Screens Touch Screen (Stylus) Quarter VGA Resources - Portrait Mode x Common Controls Animation Control Common Control Windows CE Error Reporting Error Report Generator TREK-722/723 User Manual...
  • Page 66 Error Report Transfer Driver Error Reporting Control Panel VOICE OVER IP PHONE SERVICES Phone IME PC Authentication Telephony User Interface VoIP Application Interface Layer (VAIL) VAIL Database Store Phone Provisioner Reference Media Manager Real-time Communications (RTC) Client SIREN/G.722.1 Codecs TREK-722/723 User Manual...
  • Page 67 TREK-722/723 User Manual...
  • Page 68 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2013...
