User Manual
POC-127
Intel® Pineview-M N450 CPU
based Point of Care Terminal
with 12.1" LED panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POC-127 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech POC-127

Summary of Contents for Advantech POC-127

  • Page 1 User Manual POC-127 Intel® Pineview-M N450 CPU based Point of Care Terminal with 12.1” LED panel...
  • Page 2 Note! A NOTE provides additional information intended to avoid inconve- niences during operation. Part No. 2008012700 Edition 1 Printed in Taiwan November 2011 POC-127 User Manual...
  • Page 3 Repair of the device may also only be carried out by trained service personnel. Advantech recommends that a service contract be obtained with Advantech Service and that all repairs also be carried out by them. Otherwise the correct functioning of the device may be compromised.
  • Page 4 Caution! When servicing the device, always use replacement parts that are quali- fied to Advantech standards. Advantech Medical cannot warrant or endorse the safe performance of third-party replacement parts for use with our medical device.
  • Page 5 Grounding reliability can only be achieved when the equipment is connected to an equivalent receptacle marked “Hospital Only” or “Hospital Grade”. Use a power cord that matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country. POC-127 User Manual...
  • Page 6 The mark on electrical and electronic products only applies to the current European Union Member States. POC-127 User Manual...
  • Page 7 Guidance and manufacturer’s declaration - electromagnetic emissions The model POC-127 is intended for use in the electromagnetic environment specified below. The customer or the user of the model POC-127 should assure that it is used in such an environment. Emissions test...
  • Page 8 Guidance and manufacturer’s declaration - electromagnetic immunity The model POC-127 is intended for use in the electromagnetic environment specified below. The customer or the user of the model POC-127 should assure that it is used in such an environment. Immunity test IEC 60601...
  • Page 9 List of Accessories Before installing your Point of Care Terminal, ensure that the following materials have been received:  POC-127 series Point of Care Terminal  Accessories for POC-127 – CD-ROM disc-"Drivers, User's manual and Utilities"...
  • Page 10 Additional Information and Assistance Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call:  Product name and serial number  Description of your peripheral attachments ...

  • Page 11: Table Of Contents

    Figure 1.1 Dimension..............4 Figure 1.2 VESA Mounting ............4 Chapter System Setup ........7 A Quick Tour of the POC-127 ..............8 2.1.1 Front view ..................8 Figure 2.1 Front View of the Point of Care Terminal ....8 2.1.2 Rear view ..................
  • Page 12 Installation of Driver ..............50 7.3.3 Further information ..............51 ........................ 52 7.4.1 Advantech SUSI Introduction............52 7.4.2 Install Advantech SUSI driver ............. 55 ........................ 59 7.5.1 Advantech POC Dashboard Introduction........59 7.5.2 Install Advantech Dashboard driver........... 63 Chapter Utility and Hot fix ......

  • Page 13: Chapter 1 General Information

    Chapter General Information...

  • Page 14: Introduction

    12.1” color TFT LCD display, Single DVI-I Port, Dual on-board 10/ 100/1000 PCI-E Ethernet controller, Quad COM ports, Quad USB 2.0 ports and a 24- bit stereo audio controller. With a 2.5” SATA HDD drive optional, the POC-127 is an user-friendly computer. For system integrators, this highly integrated multimedia sys- tem lets you easily build a Point of Care (POC) terminal into your applications.
  • Page 15 375 mmHg to 760 mmHg (transportation) Water/dust IPX1 compliant Resistance Dimensions 348 x 287 x 92 mm (13.70" x 11.22" x 3.62") Physical (W x H x D) Characteristics Weight 4.5 kg Platform & utility XP Professional, Windows 7, SUSI POC-127 User Manual...
  • Page 16 Unit: mm 348.47 92.3 Figure 1.1 Dimension VESA Mounting: 75 x 75 mm Figure 1.2 VESA Mounting POC-127 User Manual...
  • Page 17 During normal use of the POC-127 may become soiled and should, therefore, be cleaned regularly. Agents: Green tinctured soap and Enzymatic detergents Steps: Wipe the POC-127 with a clean cloth that has been moistened in the cleaning solution. Prepare agent per manufacturer’s instructions or hospital protocol.
  • Page 18 POC-127 User Manual...

  • Page 19: Chapter 2 System Setup

    Chapter System Setup...

  • Page 20: A Quick Tour Of The Poc-127

    A Quick Tour of the POC-127 Before you start to set up the POC-127, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illus- trated in the figures below.
  • Page 21 2-2 and 2-3 Rear view VESA mounting 75mm x 75mm IEEE 1394a port Ethernet (network) ports labeled TCP/IP (LAN1) USB1-USB4 ports* COM1 ®C COM2 serial ports Line-out, Microphone-in & Line in jack VGA port KB/MOUSE (keyboard/mouse) PS/2 port POC-127 User Manual...

  • Page 22: Bottom View

    Equipotential terminal need link to hospital ground/earth system before system boot to protect operator and system. 2.1.4 Left side view Figure 2.5 Left side view Smart Card Reader ( option and the smart card for sample only ) POC-127 User Manual...

  • Page 23: Installation Procedures

    Installation Procedures 2.2.1 Connecting the power cord The POC-127 could only be powered by a DC power adapter (SINPRO Model no.MPU63-107 or HPU100-107). Be sure to always handle the power cords by hold- ing the plug ends only. Follow these procedures in order: Connect the female end of the power adapter to the DC jack of the panel PC.

  • Page 24: Switch On The Power

    Figure 2.9 Press the power button to boot system Running the BIOS Setup Program Your POC-127 is likely to have been properly set up and configured by your dealer prior to delivery. You may still find it necessary to use the BIOS (Basic Input-Output System) setup program to change system configuration information, such as the cur- rent date and time or your type of hard drive.

  • Page 25: Running The Bios Setup Program

    For your reference, the directory of drivers on the "Drivers and Utilities" CD-ROM “d:\driver” folder Note! The drivers and utilities used for the POC-127 panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities.
  • Page 26 POC-127 User Manual...

  • Page 27: Chapter 3 Chipset

    Chapter Chipset...

  • Page 28: Introduction

    Introduction The POC-127 uses the Intel® Atom Processor N400 series (code named Pinev- iew-M single-core processor) referred as the processor and Intel® I/O Controller Hub 8 (ICH8) Family Express Chipset referred as the chipset. Processor features:  The processor is built on 45-nanometer Hi-K process technology ...
  • Page 29 System Management Bus (SMBus) Specification, Version 2.0 with additional support for I2C devices)  Supports Intel® High Definition Audio  Low Pin Count (LPC) interface  Firmware Hub (FWH) interface support  Serial Peripheral Interface (SPI) support POC-127 User Manual...

  • Page 30: Installation Of Intel(R) Rapid Storage Technology Driver

    Note! <Enter> means pressing the °×Enter°± key on the keyboard. Note! Before you install the graphic driver of POC-127, please ensure you have installed the “Intel Chipset Software Installation Utility”. You can find this driver in the Utility CD-ROM. Note! The resolution of window display will be fix on 640 x 480 before you install Graphics driver.

  • Page 31: Installation Of Chipset Driver

    POC- 127. 3.3.1 Installation for Windows XP Step 1.Double Click ”infinst_autol.exe” in D:\Driver\XP\Chipset folder. The Install dia- log will appear. Step 2.Click Next to continue. Step 3.Read License Agreement and click Yes to proceed. POC-127 User Manual...
  • Page 32 Step 4.Read file information and click Next to proceed. POC-127 User Manual...
  • Page 33 Step 5.When the 'Setup COMPLETE' message appears click Finish to restart your computer. POC-127 User Manual...

  • Page 34: Installation Of Graphics Driver

    POC- 127. 3.4.1 Intel chipset graphics driver install Step 1.Double Click “winxp.exe” in D:\Driver\XP\VGA folder. Step 2.Driver Information will appear as the picture below, click Next to continue. Step 3.Click Next to continue. POC-127 User Manual...
  • Page 35 Step 4.Read License Agreement and click Yes to proceed. Step 5.Read file information and click Next to proceed. POC-127 User Manual...
  • Page 36 Step 6.When the 'Click Next to continue’ message appears click Next to proceed. POC-127 User Manual...

  • Page 37: Further Information

    7.When the 'Setup Is Complete' message appears click Finish to restart your computer. Further information For further information about the installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Intel website: www.intel.com Advantech websites: www.advantech.com...
  • Page 38 POC-127 User Manual...

  • Page 39: Chapter 4 Audio Interface

    Chapter Audio Interface...

  • Page 40: Introduction

    Before installing the audio driver, please take note of the procedures detailed below. You must know which operating system you are using in your POC-127, and then refer to the corresponding installation flow chart. Just follow the steps in the flow chart.
  • Page 41 Step 2.Click 'Next' to continue. Install program will install driver and utility. It will spend a period of time processing. Step 3.When the 'InstallShield Wizard Complete' message appears click Finish to restart your computer.. POC-127 User Manual...

  • Page 42: Further Information

    Further information For further information about the Audio interface installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the follow- ing web resources. Realtek website: www.realtek.com.tw Advantech websites: www.advantech.com www.advantech.com.tw POC-127 User Manual...

  • Page 43: Chapter 5 Pci Express Ethernet

    Chapter PCI Express Ethernet...

  • Page 44: Introduction

    Introduction The POC-127 is equipped with a high performance PCIe Ethernet chipset Intel 82567V which is fully compliant with IEEE 802.3 10/100/1000 Mbps standards. The Ethernet port provides a standard RJ-45 jack. Product Features (82567V):  Reduced power consumption during normal operation and power down modes ...
  • Page 45 Step 2.Click Next to continue. Step 3.Read License Agreement and select “accept the terms in the license Agree- ment” and click Next to proceed. POC-127 User Manual...
  • Page 46 Step 4.When the 'Setup Options' message appears click Next to proceed. Step 5.When the 'Ready to Install the program' message appears click Install to pro- ceed. POC-127 User Manual...

  • Page 47: Further Information

    7.When the 'InstallShield Wizard Complete' message appears click Finish to finish the install program. Further information For further information about the installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Intel website: www.intel.com Advantech websites: www.advantech.com...
  • Page 48 POC-127 User Manual...

  • Page 49: Touch Panel

    Chapter Touch Panel...

  • Page 50: Introduction

    Introduction The POC-127 is supported with a system integrated touch panel. SAW and Resistive touch screen types can be chosen. SAW type was controlled by system COM5, and Resistive Touch Sensor was linked to system COM6. Caution! Please don't install both SAW Touch driver and Resistive Touch driver at same system.
  • Page 51 Step 3.Click Next to continue.Because POC-127’s touch controller is controlled by COM6, please do not select the “Install PS/2 interface driver”. POC-127 User Manual...
  • Page 52 4.Click Next to continue. “Install RS232 interface driver” is selected by default. Step 5.Click Next to continue. Please select “None” for “Do 4 point calibration”. The driver install program will do this 4 point calibration when the install com- pletes. POC-127 User Manual...
  • Page 53 Step 6.Click OK to continue. Step 7.Click Next to continue. Please select “Support Multi-Monitor System”. POC-127 User Manual...
  • Page 54 Step 8.Click Next to continue. If you want to change the driver destination folder, you can click the Browse button to change the folder. Step 9.Click Next to continue. POC-127 User Manual...
  • Page 55 Step 11.Click Yes to continue. The install program will search the touchscreen con- troller, and find it on COM6. Calibrate the panel: Step 12.Click Yes to continue. Please do 4 point calibration to calibrate the touch screen. POC-127 User Manual...

  • Page 56: Further Information

    13.Touch 'X' once at each of the 4 corners on the panel. Please touch each ‘X’ icon at the corners until the icon stops blinking. Further information For further information about the installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources.

  • Page 57: Optional Devices

    Chapter Optional Devices...

  • Page 58: Rfid

    7.1.1 RFID POC-127 contains ASTAG PMHNFC0003-3 RFID Module. RFID reader helps nurses identify patients and verify themselves as authorized care- givers, as well as reducing prescription errors Feature HF READER SUPPORTS: ISO-14443A, ISO-14443B, ISO-15693, Felic, ISO-18000-3 mode 1, Mifare UltraLight...
  • Page 59 Step 3.Click “Next” to continue. Step 4.When the complete message appears click 'Finish' to finish the install pro- gram. POC-127 User Manual...

  • Page 60: Further Information

    7.1.3 Further information For further information about the installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Advantech websites: www.advantech.com www.advantech.com.tw 7.2.1 Smart Card Reader Introduction POC-127 contains Smart Card Reader Module. Smart card reader built-in help...

  • Page 61: Further Information

    7.2.3 Further information For further information about the installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Advantech websites: www.advantech.com www.advantech.com.tw POC-127 User Manual...

  • Page 62: Wireless Module Introduction

     Low power consumption and high performance  Enhanced wireless security 7.3.2 Installation of Driver Install Windows Installer Step 1.Double Click “Setup.exe” in D:\Driver\XP\Wireless\Install_CD folder. The Install dialog will appear. Step 2.Click Install be begin the installation. POC-127 User Manual...

  • Page 63: Further Information

    Step 3. Click Finish to exit the wizard. 7.3.3 Further information For further information about the installation in your POC-127, included Driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Advantech websites: www.advantech.com www.advantech.com.tw POC-127 User Manual...

  • Page 64: Advantech Susi Introduction

    This is a time-consuming job and requires lots of expertise. Advantech has done all the hard work for our customers with the release of a suite of APIs (Application Programming Interfaces), called the Secured & Unified Smart Interface (SUSI).
  • Page 65  Hardware Monitor The Hardware Monitor (HWM) API is a system health supervision API that inspects certain condition indexes, such as fan speed, temperature and voltage. POC-127 User Manual...
  • Page 66 The Brightness Control API allows a developer to interface Windows XP and Win- dows CE PC to easily control brightness.  Backlight The Backlight API allows a developer to control the backlight (screen) on/off in Win- dows XP and Windows CE. POC-127 User Manual...

  • Page 67: Install Advantech Susi Driver

    Flexible Upgrade Possibilities SUSI supports an easy upgrade solution for customers. Customers just need to install the new version SUSI that supports the new functions. 7.4.2 Install Advantech SUSI driver Step 1.Double Click “Setup.exe” in D:\Driver\XP\SUSI folder. The Install dialog will appear.
  • Page 68 Step 3.Read and accept End-User License Agreement. Click Install to continue. POC-127 User Manual...
  • Page 69 Step 4.Microsoft .NET Framework 2.0 has been installed, click Finish to continue. Step 5.Click Next to install SUSI. POC-127 User Manual...
  • Page 70 Step 6.Read and accept License Agreement. Click Next to continue. Step 7.Click Install to begin installation. Step 8.Click OK to finish installation and to restart system. POC-127 User Manual...

  • Page 71: Advantech Poc Dashboard Introduction

    Clicking the icon in the top right corner will close the application. Brightness Control There are 7 levels of display brightness in POC-127. Clicking the icon in “Brightness Control” panel will decrease the brightness in the panel. And the light bar will also show the current brightness level at the same time.
  • Page 72 “Display Control” panel, the Dashboard will turn off the display. Hotkeys “O” and “F” switch display status. Volume Control Clicking the icon in “Volume Control” panel will decrease the volume and clicking the icon will increase it. POC-127 User Manual...
  • Page 73 Touch Control Clicking the icon in “Touch Control” panel will enable touch functions, and clicking the icon will disable them. (Once touch funtions have been dis- abled, you will need to use the mouse to re-enable them.) POC-127 User Manual...

  • Page 74: Install Advantech Dashboard Driver

    Battery Pack. “Total Power Remaining” shows the capacity of the battery pack. “Power Source” shows whether “AC” or “Battery” is being used. 7.5.2 Install Advantech Dashboard driver Step 1.Double Click “dotNetFx40_Full_x86_x64.exe” in D:\Driver\XP\Dash board folder. To begin installing Microsoft .NET Framework 4.0.
  • Page 75 Step 2.Execute “POC Dashboard.exe”, then showing the dashboard screen. POC-127 User Manual...
  • Page 76 POC-127 User Manual...

  • Page 77: Utility And Hot Fix

    Chapter Utility and Hot fix...

  • Page 78: Introduction

    Introduction The POC-127 system needs a specific utility or hot fix to support special functions. Wakeup by external USB device at S3 resume (wakeup) POC-127 supports three different sleep (suspend) modes, they are: S1: Power On Suspend - system will stop the clock, turn off LCD backlight, but keep all power on.

  • Page 79: Operation And Safety Information

    Chapter Operation and Safety information...
  • Page 80 * You want to remove/install any parts Thermal The rear metal VESA mount holes of the POC-127 case functions as a cooling air flow inlet. And POC-127 case side vent hole as a cooling air flow outlet. These air inlet and outlet transfer heat from inside the computer to the cooler air out- side.

  • Page 81: Appendix Amb Connector Map And Table

    Appendix MB Connector Map and Table...
  • Page 82 EC Reset Button Smart Card Reader Connector COM1 RS232/422/485 Jumper Disk On Module(DOM) Connector SATA1 Signal Connector Internal Power Button SATA0 Signal Connector Speaker Connector SATA1 Power Connector Power Button SATA0 Power Connector Power LED Connector Keyboard Matrix Connector POC-127 User Manual...
  • Page 83 1394a Touch Screen Connector MINI-PCIE Connector USB(Port3) LVDS Connector USB(Port2) USB(Port1) USB(Port0) COM 1 COM 2 Mother Board Connector Table (Bottom Side) MB Connector Table (Top Side) DescriptionNo.Description RTC Battery Connector Description No. Description RTC Battery Connector POC-127 User Manual...
  • Page 84 POC-127 User Manual...

  • Page 85: Appendix Bpcm-8708 Mb Jumper Setting

    Appendix PCM-8708 MB Jumper setting...
  • Page 86 Jumper Setting: CN10 Clear CMOS CN45 System Reset CN26 COM1 (RS232/422/485) Select CN10 Clear CMOS Description Clear CMOS Setup Setting Function (1-2) Clear CMOS Setup (No Connect) Normal Operation (Default) POC-127 User Manual...
  • Page 87 5 V (Default) (2-3) 3.3 V CN26 COM1 RS232/422/485 output type setting Description COM1 RS232/422/485 output type setting Setting Function (5-6), (7-9), RS232 (Default) (8-10), (13-15), (14-16) (3-4), (9-11) RS422 (10-12), (15-17) (16-18) (1-2), (9-11) RS485 (10-12), (15-17) (16-18) POC-127 User Manual...
  • Page 88 POC-127 User Manual...

  • Page 89: Poc-127 Cleaning And Disinfecting

    Appendix POC-127 Cleaning and Disinfecting...

  • Page 90: Point-Of-Care Terminal Cleaning And Disinfecting

    Point-of-Care Terminal Cleaning and Disinfecting During normal use of the POC (Point-of-Care Terminal) the device may become dirty and should be regularly cleaned. Steps: Prepare cleaning agent per manufacturer’s instructions or hospital protocol. Wipe the POC with a clean cloth that has been moistened in the cleaning solu- tion.
  • Page 91 XXX-XXXX User Manual...
  • Page 92 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2011...
