Figure 1. Demo Voice Menu Flowchart
CSP Prompt
Say something to barge in
or press any DTMF
Send Fax Prompt
Dial server mailbox
number to store fax in
* - Quit
Fax Sent Prompt
Announces fax sent
Repeat Fax menu
IP Media Server for HMP Demo Guide — July 2005
Main Menu
Select one of the following:
1 - Voice Mail
4
2 - Fax
4 - CSP
* - Quit
Fax Menu
1 - Send fax (to server)
2 - Receive fax (from server)
* - Quit
1
2
Receive Fax Prompt
Dial fax number that will
receive fax from server
* - Quit
Fax Received Prompt
Announces fax received
Repeat Fax menu
Confirm Message Saved
Prompt
Confirm message
Return to Voice Mail prompt
1
Voice Mail Prompt
1 - Record Message
2 - Listen to message
2
from a mailbox
* - Quit
1
Send Message Prompt
Enter Mailbox Number
* - Quit
Start Record Prompt
2 - Start/Stop Record
* - Quit
2
2
Stop Record Prompt
2 - Discard message and
re-record message to
same mailbox
3 - Confirm message
4 - Replay message
* - Quit
3 4
Replay Message
Replay Stop Record
Prompt
Running the Demo
2
Listen Message Prompt
Enter Mailbox Number
(Message is played)
* - Quit
Stop Listen Prompt
2 - Discard message
and quit
* - Save message and
quit
23
