Intel
ISP1100 Internet Server
Quick Start Guide
A Guide for Technically Qualified Assemblers of Intel
Subassemblies/Products
Before You Begin ................................................................................................................. 2
FCC/Emissions Disclaimer........................................................................................... 2
Cautions and Warnings ............................................................................................... 2
Safety and Regulatory Requirements .......................................................................... 3
Site Criteria.................................................................................................................. 3
Unpack and Inspect the Server ............................................................................................ 3
Check the Accessories ................................................................................................ 4
Check the Power Cord................................................................................................. 4
Install Components............................................................................................................... 5
Tools and Supplies Needed ......................................................................................... 5
Remove the Cover ....................................................................................................... 5
Install the Processor .................................................................................................... 6
Install the Memory ....................................................................................................... 8
Install the Hard Drive(s) ............................................................................................. 10
Install PCI Add-in Card(s) .......................................................................................... 12
Close the Cover ......................................................................................................... 17
Install the Rackmount Brackets ................................................................................. 17
Rackmount the Server........................................................................................................ 18
Power Up the Server .......................................................................................................... 19
Access the Additional Documents ...................................................................................... 20
Need Help? ........................................................................................................................ 22
The most current version of this document and other documents relating to the Intel
Server can be found at http://www.intel.com/isp
Copyright © 2000 Intel Corporation. All rights reserved. No part of this document may be copied, or reproduced in
any form, or by any means without prior written consent of Intel.
Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any
errors that may appear in this document. Intel makes no commitment to update nor to keep current the information
contained in this document.
† Third-party brands and trademarks are the property of their respective owners.
Order Number: A10529-001
®
Identified
®
ISP1100 Internet
Advertisement
Table of Contents
Related Manuals for Intel ISP1100
Summary of Contents for Intel ISP1100
-
Page 1: Table Of Contents
Intel. Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may appear in this document. -
Page 2: Before You Begin
This guide is for qualified technical personnel with experience installing and configuring servers. CAUTIONS Perform the procedures in this guide only at an ESD workstation since the server components can be extremely sensitive to ESD. If no such station is Intel ISP1100 Internet Server Quick Start Guide... -
Page 3: Safety And Regulatory Requirements
Isolated from strong electromagnetic fields and noise caused by electrical devices such as elevators, copy machines, air conditioners, large fans, large electric motors, radio and TV transmitters, and high-frequency security devices. For EMI information, refer to the Intel ISP1100 Internet Server Product Guide. -
Page 4: Check The Accessories
Rating: Power cords must be rated for available AC voltage and have a current rating at least 125% of the server current rating. (Refer to the Intel ISP1100 Internet Server Technical Product Specification included on the Intel Internet Server Resource CD-ROM shipped with the server for power requirement information.) -
Page 5: Install Components
3. Grasp the notch (B) in the front center of the cover and lift to remove the cover. OMO9429 Figure 1. Removing the Cover Intel ISP1100 Internet Server Quick Start Guide... -
Page 6: Install The Processor
III processor 650, 600E 550E, 500 Coppermine 128 KB; other Intel Celeron processors are based on Mendocino core. Remove the Processor Fan Due to space constraints, the server will not accommodate a processor with a fan mounted on top of the heat sink. Sufficient cooling is provided without a processor fan (five fans are mounted on the server chassis). - Page 7 5. With the processor in place, swing the arm (A) down until it snaps into the socket tab (B). The processor is now properly socketed. OMO9431 Figure 3. Installing the Processor Chip Intel ISP1100 Internet Server Quick Start Guide...
-
Page 8: Install The Memory
DIMM boards can be installed in any order. However, it is easier to start with the back socket and move toward the front. • Empty sockets between DIMM boards is permitted. • DIMM memory sizes can be mixed if all installed DIMM memory size is either unbuffered or registered. Intel ISP1100 Internet Server Quick Start Guide... - Page 9 All memory components used with this server must comply with the following PC SDRAM specifications (refer to the Intel ISP1100 Internet Server Technical Product Specification included on the Intel Internet Server Resource CD-ROM shipped with the server for information about where to obtain these specifications): ...
-
Page 10: Install The Hard Drive(S)
1-inch hard drive. Before proceeding, be sure you are thoroughly familiar with the “Before You Begin” information at the front of this guide. Intel ISP1100 Internet Server Quick Start Guide... - Page 11 Do not overtighten the screws because the bracket sides can bend inward which affects the alignment of the tabs with the slots in the front panel. OMO9435 Figure 7. Installing the Drive in the Mounting Bracket Intel ISP1100 Internet Server Quick Start Guide...
-
Page 12: Install Pci Add-In Card(S)
Before proceeding, be sure you are thoroughly familiar with the “Before You Begin” information at the front of this guide. NOTE Set the add-in card jumpers or switches according to the manufacturer’s instructions. Intel ISP1100 Internet Server Quick Start Guide... - Page 13 1. Grasp the riser card at each end (A) and gently rock and lift the riser card until it is loose from the server board connector (B). 2. Remove the riser card from the server board connector. OMO9437 Figure 9. Removing the Riser Card Intel ISP1100 Internet Server Quick Start Guide...
- Page 14 The connectors are keyed to mate in only one direction. 2. Firmly press the add-in card(s) all the way into the mating connector on the riser card. OMO9438 Figure 10. Installing Add-in Card(s) on the Riser Intel ISP1100 Internet Server Quick Start Guide...
- Page 15 2. Remove the retention bracket. 3. Remove the filler panel (C) from the expansion slot for the type of add-in card(s) you are installing. OMO9439 Figure 11. Removing the Rear I/O Filler Panel(s) Intel ISP1100 Internet Server Quick Start Guide...
- Page 16 3. Use the Phillips screwdriver and the two screws (D) removed in the “Remove the Rear I/O Filler Panel(s)” procedure to securely attach the filler panel retention bracket (E) to the top of the server back panel. OMO9440 Figure 12. Installing the Riser/Add-in Card(s) Intel ISP1100 Internet Server Quick Start Guide...
-
Page 17: Close The Cover
3. Install the remaining rackmount bracket (D) to the opposite side of the server chassis by repeating steps 1 and 2. OMO9441 Figure 13. Installing the Rackmount Brackets Intel ISP1100 Internet Server Quick Start Guide... -
Page 18: Rackmount The Server
20 A of protection, you must provide supplemental protection for the server. If more than one server is installed in the rack, the power source for each server must be from a separate branch circuit. Intel ISP1100 Internet Server Quick Start Guide... -
Page 19: Power Up The Server
Replace the cord with the correct type. Refer to “Check the Power Cord” in the “Unpack and Inspect the Server” section at the front of this guide for power cord requirements. Intel ISP1100 Internet Server Quick Start Guide... -
Page 20: Access The Additional Documents
4. Press the Power switch (C) to apply power to the server and notice that the green LED power indicator (D) is lit. 5. Refer to the Intel ISP1100 Internet Server Product Guide available on the Intel ISP1100 Internet Server Resource CD-ROM shipped with the server for additional operating information. - Page 21 The Intel ISP1100 Internet Server Resource CD-ROM contains .pdf files of the Intel ISP1100 Internet Server Product Guide, Technical Product Specification, and this Quick Start Guide in addition to other related documents. (See “Check the Accessories” under “Unpack and Inspect the Server”...
-
Page 22: Need Help
È possibile ottenere supporto per questo prodotto al seguente indirizzo: Сведения о поддержке данного продукта можно найти по адресу: Podrá encontrar asistencia para este producto en la siguiente dirección URL: O suporte para este produto pode ser encontrado no seguinte URL: http://www.intel.com/isp Intel ISP1100 Internet Server Quick Start Guide...
