ISP2150 2U Rack Server Platform
Quick Start Guide
A Guide for Technically Qualified Assemblers of Intel
Subassemblies/ Products
FCC Declaration of Conformity.................................................................................................. 4
Cautions and Warnings ............................................................................................................... 6
Product Regulation Compliance..................................................................................................7
Safety Compliance...................................................................................................................... 7
Electromagnetic Compatibility (EMC) ....................................................................................... 7
Opening and Closing the Front Bezel ......................................................................................... 8
Locking and Unlocking the Front Bezel ..................................................................................... 9
Attaching and Removing the Front Bezel ................................................................................... 9
Open the Cover ........................................................................................................................... 9
Installing a Microprocessor....................................................................................................... 10
Installing Memory..................................................................................................................... 11
Installing a Hard Drive.............................................................................................................. 13
Installing Add-in Cards............................................................................................................. 14
Installing a Slim-Line CD-ROM Drive..................................................................................... 16
Removing a Diskette Drive....................................................................................................... 17
Re-Installing a Diskette Drive................................................................................................... 17
Close the Cover......................................................................................................................... 17
Installing the Front Bracket and Racking Your System ............................................................ 18
Installing the Front Bracket in a Cabinet................................................................................... 18
Installing the Front Bracket in a Center-Mount, Relay Rack .................................................... 20
Installing the Rail Kit and Racking Your System (Optional Accessory)................................... 21
Front Panel Controls and Indicators.......................................................................................... 25
Back Panel Connectors .......................................................................................................... ... 26
Jumpers........................................................................................................................ ............. 27
Server Board Components ........................................................................................................ 29
....................................................................................................................................... 30
Order Number: A13687-001
®
Identified
Advertisement
Table of Contents
Related Manuals for Intel ISP2150 - Server Platform - 0 MB RAM
Summary of Contents for Intel ISP2150 - Server Platform - 0 MB RAM
-
Page 1: Table Of Contents
ISP2150 2U Rack Server Platform Quick Start Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/ Products Before You Begin FCC Declaration of Conformity....................4 Cautions and Warnings ....................... 6 Product Regulation Compliance....................7 Safety Compliance........................7 Electromagnetic Compatibility (EMC) ..................7 ISP2150 Opening and Closing the Front Bezel .................. -
Page 2: Before You Begin
The ISP2150 2U Rack Server Platform Product Guide can be found at http://channel.intel.com/isp/ Copyright © 2000 Intel Corporation. All rights reserved. No part of this document may be copied, or reproduced in any form, or by any means without prior written consent of Intel. - Page 3 ICES-003 (Canada) Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques”, NMB-003 édictée par le Ministre Canadian des Communications. (English translation of the notice above) This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the interference-causing equipment standard entitled “Digital Apparatus,”...
-
Page 4: Cautions And Warnings
Cautions and Warnings WARNINGS Pressing the power button does not turn off power to this server. Disconnect the server from its power source and from any telecommunications links, networks, or modems before doing any of the procedures described in this guide. Failure to do this can result in personal injury or equipment damage. -
Page 5: Product Regulation Compliance
Product Regulation Compliance See the ISP2150 2U Rack Server Platform Product Guide for all applicable safety standards, electromagnetic compatibility (EMC) regulations, and product certification markings. Intended uses: This product was evaluated for use in computer rack cabinets within computer rooms and similar locations. -
Page 6: Isp2150
ISP2150 ® Congratulations on the purchase of your new Intel ISP2150 system. This Quick Start introduces you to your new system, guides you through rack kit installation, and helps you get the system started. The following procedures describe how operate the system’s front bezel, which covers the front panel controls and indicators. -
Page 7: Locking And Unlocking The Front Bezel
Locking and Unlocking the Front Bezel The bezel can be locked and unlocked to prevent unwanted access to the system. To lock the bezel: Remove the keys from inside the bezel (they should be taped to the inside). Close the bezel and insert the key into the lock. Turn the lock counterclockwise until it stops (about a quarter turn). -
Page 8: Installing A Microprocessor
® ® II or Pentium III processors (with 100 MHz system bus). The server supports up to two Intel Pentium If you are installing two processors, make sure they are the same speed, voltage, and stepping. Remove the new processor from its... -
Page 9: Installing Memory
Installing Memory The server only supports 100 MHz PC/100-compliant SDRAM. Install from 32 MB to 2 GB of unbuffered memory, using up to four single or double-banked DIMMs Install from 32 MB to 2 GB of registered memory, using up to four single or double-banked DIMMs OM09318 ISP2150 2U Rack Server Platform Quick Start Guide... - Page 10 Installed DIMMs must be the same speed and either all registered or all unbuffered. For a list of supported memory, call your service representative or visit the Intel Support website: http://support.intel.com/support/motherboards/server/l440gx/compat.htm CAUTION Use extreme care when installing a DIMM. Applying too much pressure can damage the socket.
-
Page 11: Installing A Hard Drive
Installing a Hard Drive Your server does not include a hard drive. You must purchase them separately and install them. The server has four hot-swappable SCSI hard drive bays. Remove the drive carrier(s) from the drive bays by unclipping the retention lever on the right side of the handle. -
Page 12: Installing Add-In Cards
Installing Add-in Cards You can only add two PCI cards to this server. You must use the PCI slots on the riser card. Do not use any expansion slots on the server board. Remove the expansion slot cover for the slot you wish to use. - Page 13 Remove add-in board from its protective wrapper. Set jumpers or switches according to the manufacturer’s instructions. Hold board by its top edge or upper corners. Firmly press it into an open expansion slot on the riser card. The tapered foot of the board-retaining bracket must fit into the mating slot in the expansion slot frame.
-
Page 14: Installing A Slim-Line Cd-Rom Drive
Installing a Slim-Line CD-ROM Drive Your server does not come with an integrated slim-line CD-ROM drive. You must purchase one separately and install it. Remove the drive from its protective wrapper, and place it on an anti-static surface. Set any jumpers and/or switches on the drive according to the drive manufacturer’s instructions. -
Page 15: Removing A Diskette Drive
Removing a Diskette Drive Disconnect the power (B) and signal (A) cables from the diskette drive. The connectors are keyed for ease in reconnecting them to the drive. Remove and save the screws (C) that secure the diskette drive carrier to the front of the chassis. -
Page 16: Installing The Front Bracket And Racking Your System
Installing the Front Bracket and Racking Your System The ISP2150 system comes with mounting bracket hardware that allows you to install it into cabinets and relay racks. The following procedures describe how to mount the ISP2150 system in each type of chassis. CAUTION Some racks and cabinets may not support the installation of the system. - Page 17 Mount the back support bracket to the cabinet. Left (A) and right and left rear mounting brackets also come with the system. Mount the rear brackets in the desired position in the cabinet using the supplied mounting bolts (C) supplied by the cabinet manufacturer. Slide the system into the back support bracket.
-
Page 18: Installing The Front Bracket In A Center-Mount, Relay Rack
Installing the Front Bracket in a Center-Mount, Relay Rack Attach the left and right front brackets to the system. Your system comes with left and right front brackets (A) and mounting bolts (B) to attach them to the system. Mount the brackets mid-way down the sides of the system as shown in the figure. -
Page 19: Installing The Rail Kit And Racking Your System (Optional Accessory)
Installing the Rail Kit and Racking Your System (Optional Accessory) The rail kit that comes with your system allows you to install it into a four-post, network server cabinet (e.g. APC Netshelter). If the cabinet is not of this general type, you will have to purchase a separate rail kit that is specific to your cabinet. - Page 20 Here is a combination side and rear view of the chassis after the right inside rail has been attached. Locate the front and rear rail brackets for one side of the rail kit. One pair (A and B) exists for each side of the cabinet rack.
- Page 21 Attach the side rail system’s outer pieces (total of two) to the rail brackets you installed in step six. To attach the front part of an outer piece to a rail bracket, you must reveal the access hole (A) by sliding the innermost piece toward the back.
- Page 22 Extend the right and left rails (A) so they fully extend in front of the cabinet rack. The rail system is now ready to receive the chassis. OM09141 10. Lift the chassis with its front facing you and carefully guide the inner rail (A), which is mounted to the chassis system, into the outer pieces (B) you attached in previous...
-
Page 23: Technical Reference
Technical Reference Front Panel Controls and Indicators OM09320 Power button Sleep button Reset button Power LED NIC activity LED Fail LED Disk activity/fail LEDs Hard drive bay Hard drive eject lever CDROM drive bay Diskette eject button Diskette drive Diskette activity LED ISP2150 2U Rack Server Platform Quick Start Guide... -
Page 24: Back Panel Connectors
Back Panel Connectors H G F OM09321 Mouse connector Parallel port connector PCI expansion slots AC input power connector Power supply fault indicator Video connector USB connectors RJ45 network connector Serial port connector (Com 1) Serial port connector (Com 2) Keyboard connector NIC LED Color If it’s on... -
Page 25: Jumpers
Jumpers Nine 3-pin jumper blocks that control various configuration options, as shown in the figure below. Refer to the ISP2150 2U Rack Server Platform Product Guide for more information. WOL ENABLE J5A2 WR EN J4J2 J3J1 BMC FRC UP BIOS WR EN J2J1 INT DET RCVRY BOOT... - Page 26 Jumper Jumper Name Pins Block (default in bold) What it does at system reset J2J1 PSWD CLR 5-6, Protect Maintains the current system password. 6-7, Erase Clears the password. J2J1 RCVRY BOOT 9-10, Normal System attempts to boot using the BIOS stored in flash memory.
-
Page 27: Server Board Components
Server Board Components F G H OM08561 Fansink connector 2 Ultra wide SCSI connector Secondary processor Server Monitor Module (SMM) connector Fansink connector 1 External Wake on LAN connector Primary processor Ultra2/LVD SCSI connector DIMM slots Hard drive LED connector Main power connector Intelligent Chassis Management Bus (ICMB) header ATX aux power connector... -
Page 28: Getting Help
È possibile ottenere supporto per questo prodotto al seguente indirizzo: Podrá encontrar asistencia para este producto en la siguiente dirección URL: O suporte para este produto pode ser encontrado no seguinte URL: http://www.intel.com/isp/ ISP2150 2U Rack Server Platform Quick Start Guide...
