Intel ISP1100 Installation Manual
Internet server, rail option kit
Hide thumbs
Also See for ISP1100:
- Product manual (81 pages) ,
- Quick start manual (32 pages) ,
- Installation manual (24 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Intel ISP1100
Summary of Contents for Intel ISP1100
- Page 1 Rail Option Kit Installation Guide for Intel ISP1100 Internet Server ®...
- Page 2 Intel. Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Introduction This document explains how to install the Intel ISP1100 Internet Server in a four post rack with sliding rails. Before you begin: Make sure you have the following parts: • Two (2) rail assemblies • Two (2) front brackets (short) •...
- Page 4 Slide the chassis section (C) out of the slider section until it locks, then press the lock arm (D) on the chassis section to release it from the slider section. Pull the chassis section out of the slider section. OM09755A Intel ISP1100 Internet Server Rail Kit...
- Page 5 Align the holes in the chassis section (A) with the holes in the server. Do not use the front hole on the server. Fasten the chassis section to side of the server with four 10/24 x 0.25” panhead phillips screws (B). OMO9763 Intel ISP1100 Internet Server Rail Kit...
- Page 6 Because the rack section is a fixed length, you use the bracket placement to set the rail assembly length so the rail assembly fits your rack. Intel ISP1100 Internet Server Rail Kit...
- Page 7 Fasten the bracket to the rail assembly. Tighten the screws holding the rear bracket to the rack section. Be careful not to move the rear bracket while you are tightening the screws. OM09740 Intel ISP1100 Internet Server Rail Kit...
- Page 8 For each assembled rail: Fasten the front bracket to the rack using two screws (A) provided with the rack. OM09756A Fasten the rear bracket to the rack with two screws (A) provided with the rack. OM09756B Intel ISP1100 Internet Server Rail Kit...
- Page 9 Gently slide the server into the rack, making sure that all the rollers go into the channel. OM09754 Use the bolts provided with the rack to fasten the server’s front flanges (A) to the rack. OM09758 Intel ISP1100 Internet Server Rail Kit...
-
Page 10: Removing The Server From The Rack
Slide the server out of the rack as far as you can. When the rail assembly locks, press the lock arm (A) on both sides to release the server. OM09762 Remove the server from the rack. Intel ISP1100 Internet Server Rail Kit... - Page 12 Document number: A17803-001...
