Lexmark 3200 Service Manual page 39

3.1.1.19 Frequent double feed and skew
Cause
Paper setting
failure
Paper failure
ADF connector
slip-off
Pad assembly
failure
ADF unit failure
3.1.1.20 Strange sound generated (ADF)
Cause
Paper setting
failure
paper failure
ADF connector slip-
off
ADF unit failure
Relevant Unit Check Method
Operation error Is the paper
correctly set in
the paper chute?
Operation error Is the specified
paper used
ADF unit Visual check of
motor rotation
Pad assembly Check the pad
assembly for
wear and tear.
ADF unit Replace the ADF
unit.
Table 3.13
Relevant Unit Check Method
Operation Is the paper
error correctly set in the
paper chute?
Operation Is the specified
error paper used?
ADF unit Visual check of
motor rotation
ADF unit Replace the ADF
unit
Table 3.14
3-17
Maintenance Remark
Method
Teach users to None
properly position
the paper
None None
Connect the None
connector.
Replace the pad None
assembly/ touch
spring unit.
Replace the ADF None
unit.
Maintenance
Method
Teach users to
properly position
the paper
None
Connect the
connector.
Replace the ADF
unit.
Remark
None
None
None
None
