Lexmark 3200 Service Manual page 16

Pin Assignment for ADF Video Circuit J9:
Pin No. Name
1
2
3
4
5 B/W
6
7
8
9
10
11
12
13
14
Pin Assignment for ADF Video Circuit J8:
Pin No. Name
1
2
3
4
5
6
Function
H.G. Inverter Ground
+24V Analog +24V Power Supply
GND +5V GND
+5V +5V Power Supply
CCD B/W Control Switch
SH Channel Shift Gate
RS CCD Reset Gate
Clamp CCD Clamp Signal
GND +5V GND
PH2 CCD Clock Phase
PH1 CCD Clock Phase
H24G +24V Ground
A.G Analog Ground
+24Va Analog +24Va Power Supply
Function
A.G Analog Ground
VOR CCD Red Channel Output Signal
A.G Analog Ground
VOG CCD Green Channel Output Signal
A.G Analog Ground
VOB CCD Blue Channel Output Signal
1-12
