4.3.9 Parts That Must Not Be Disassembled
Parts shown below must not be disassembled because they are adjusted at the factory.
4.3.9.1 CCD Board Screws
Screws for CCD board in the optical chassis unit are as shown.
Figure 4.12a Flatbed CCD board screws
Figure 4.12b ADF CCD board screws
4-10
Fixing
Screws
Fixing
Screws
