1.5 Device Configuration

This section describes the device configuration of the multifunction product.

Outer View

Extension
1394 Port
Auto Document
Feeder
Output
Paper Tray
Extension
Figure 1.1 3200MFP Outer View
Paper Feed
Tray
Power Port
1-4
Document
cover
LCD-display
Control
Panel
Power Switch
