4.4.7 ADF Inverter Removal

1.

Remove the ADF optical chassis (See subsection 4.4.5).

2.

Disconnect the ADF inverter cable.

3.

Remove the ADF inverter.

Figure 4.18 ADF Unit Removal

4-16

ADF inverter

cable
