Digital Input (DI)

The DI socket allows the IP camera to receive input from an external device.
The external device should have the ability to drive voltage on the connected DI wire to
the triggering voltage level in order to notify the IP camera of any event of interest. The IP
camera will then process the event notification according to the specific event rules.
Triggering voltage Level: LOW or HIGH
Users should select the option according to the capability of their external device.

Audio Detection

Users can schedule an event to be triggered if there is a change in the sound level of a
monitored area. Audio detection can be used to measure change in the ambient voice.
Select the sensitivity from the drop-down menu.
Sensitivity - is used to adjust the sensitivity of the sound level from 10 - 100%. The default
sensitivity is 50%.
Click Apply to apply settings or Cancel to cancel changes.
