User Manual
Ascom i75 VoWiFi Handset
Note: The Soft key Menu is a default setting but all Soft key settings can be changed by
the user.
2.4.5

Hot keys

Any key "0"–"9" can be set to a Hot key. A Hot key can be programmed to give access to
frequently used functions such as dialling a specific handset number, sending data, a
short-cut to the menu, or sending a message. Note that the possibility to define a Hot key
can be locked by your system administrator.
2.4.6

Volume Button

The Volume button is used for increasing/decreasing the volume. The adjusted volume is
saved in the handset.
2.4.7

Mute Button

The Mute button is used for silencing the audible signals in stand-by mode, silencing the
ring signal at an incoming call, and also to turn off/on the microphone during a call.
2.4.8

Alarm Button

The red Alarm button is used for sending alarms, testing the alarm function (test alarm),
and for calling a predefined number after an alarm.
2.4.9

Alpha Numeric Keys

In some applications you have the possibility to write letters as well as numbers, which is
indicated by the ABC icon. Pressing the numerical keys will now give you access to the
alphabet plus some special characters according to the picture beneath.
. , - ? ! & @ " ' : ; ( ) / \ _ ^ 1
G H I Ï Ì Î Í 4
P Q R S ß 7
Switch between upper
and lower case.
Add pause "P" in
phone numbers.
In Stand-by Mode
In stand-by mode short presses on the keys enter the digits, and the characters * and #.
A long press on a key "0" - "9" activates the programmed Hot key function.
2006-09-22/ Ver. B
Figure 7.
A B C Å Ä Æ À Á Â Ã Ç 2
Space % $ £ ± + =
¿ < > # ½ µ § ° ¦
D E F È É Ê Ë 3
J K L 5
M N O N Ö Ø Ò Ó Ô Õ 6
T U V Ü Ù Ú Û 8
W X Y Z Ý 9
Switch between text
and number input mode.
Hold
0
TD 92319GB
