VoiceFinder AP2120 VoIP Gateway User's Guide Version 1.00
[Procedure]
Order
1
2
3
4
5
6
[Related Commands and Syntax]
Standard IP Access-List: The standard IP address-lists uses only the source IP
address in checking the access conditions.
access-list <access-list-number> {deny/permit} <source-address > <source
wildcard>
1. Creates an access-list.
2. access-list-number: Any number within 0 to 29, source: Source Network
3. Instead a pair of "source" and "source-wildcard," the user can use a pair
4. Wildcard is the inverse mask. For example, if the user writes 132.1.20.1
5. Since the default is the deny value, it is recommended to use "Permit Any
AddPac Technology Co., Ltd.
Go to the configuration mode.
Create an access-list defining the access-list number and access
conditions.
Go to the interface configuration mode.
Enter into the IP configuration mode.
Apply the access-list that has been set to the corresponding
interface.
Decide where to apply the access conditions – inbound packets or
outbound packets.
Use "Show access-list" command to check if the access-list has been
correctly set.
Address, Source-wildcard: Inverse mask of the source address
of "any (any address)" and "host (a certain address.)"
255.255.255.0 network in a wildcard form, the network will be 132.1.20.1
0.0.0.255.
Option" at the last line to permit all packets that do not satisfy conditions.
Operation
