VoiceFinder AP2120 VoIP Gateway User's Guide Version 1.00
tones with greater fidelity than is possible in-band for most low-bandwidth
codecs, such as G.729 and G.723. Without the use of DTMF relay, calls
established with low-bandwidth codecs may have trouble accessing
automated DTMF-based systems, such as voice-mail, menu-based ACD
systems, and automated banking systems.
5.7.4.5.5.
Example
The following example configures DTMF relay with the h245-alphanumeric
option when sending DTMF tones to dial-peer 103:
dial-peer voice 103 voip
dtmf-relay h245-alphanumeric
The next example configures the gateway to send DTMF in-band (the default)
when sending DTMF tones to dial-peer 103:
dial-peer voice 103 voip
no dtmf-relay
5.7.4.6.

forward-digits

To set the number of the forwarding digit of the outbound POTS as a random
number not by using the default method, use "forward-digits" command in the
dial-peer setup mode.
destination pattern by the default method, add "no" command.
forward-digits { from | last } number
no forward-digits
5.7.4.6.1.
Syntax
Keyword / Argument
from
last
number
AddPac Technology Co., Ltd.
To forward digits that do not match with the
Forwards the called party number from the
designated digit.
Forwards last digits of the called party number as
designated.
Number of digits to forward.
from 0 to 100. If the designated value is higher
than the maximum digits that can be forwarded,
only the digits that can be forwarded at maximum
Description
The value ranges
265
-
-
