VoiceFinder AP2120 VoIP Gateway User's Guide Version 1.00
access-group <access-list-number> [in/out]
An interface command. Applies the access-list to the incoming packet or
the outgoing packet of the corresponding interface.
Extended IP Access-List: To check access conditions, the extend IP access-list
uses source IP address, destination IP address, protocol ID, application port
number and establishment status.
access-list
<source
[port-number][established]
1. Creates Access-list.
2. Option explanation
AddPac Technology Co., Ltd.
<access-list-number>
wildcard> <destination>
1) access-list-number : Extended Access-List (Number in range of
30~59)
2) protocol : protocol ID Number or protocol name (Ex: TCP, ICMP, UDP
IP and so on)
3) source : Source Network Address,
4) Source-wildcard : Inverse Mark of Source Address
5) Destination : Destination Network Address
6) destination-wildcard : Inverse Mask of Destination Address
7) operator : operator for Port #
eq : equal
gt : greater then
lt : less then
neq : not equal
8) port-number: As application port number, well known port # is as
follows:
chargen : Character generator (19)
daytime : Daytime (13)
discard : Discard (9)
domain : Domain Name Service (53)
echo : Echo (7)
finger : Finger (79)
{deny/permit}<protocol>
<destnation-wildcard>
<source>
[operator]
