VoiceFinder AP2120 VoIP Gateway User's Guide Version 1.00
1.2.

Main Features

Information
VoiceFinder AP2120 VoIP Gateway is for enterprises (main & branch offices)
and public offices with Ethernet interface and 4 port FXS interface of
cutting-edge compression algorithem.
interface slot for FXS, FXO and E&M according to users needs.
VoiceFinder AP2120 VoIP Gateway offers superior solution for SOHO and SME .
Also, VoiceFinder AP2120 VoIP Gateway supports various voice modules to
meet the customers' service needs. Along with easy installation and
management, it supports Static, RIP v1/2, OSPF v2 Routing and can be directly
connected to High-speed Internet Modem such as ADSL.
Hardware Description
VoiceFinder AP2120 VoIP Gateway is based on cutting-edge embedded H/W
technology offering various voice interface with ample system memory. The
key H/W features are as shown below.
Supports various routing/bridging protocols
AddPac Technology Co., Ltd.
High-performance VoIP service solution integrating voice and data
Modularized H/W structure realizing high extensibility
High-performance 32bit RISC Microprocessor structure
Independent, high-performance 2-Voice Network Module Slots
Fixed 1-Port 10/100Mbps Fast Ethernet Interface for LAN Service (RJ45)
Fixed 1-Port 10Mbps Ethernet Interface for WAN Interface (RJ45)
Fixed 1-Port Asynchronous Serial Interface for Console Port (RJ45)
Optional 8-Port FXS Voice Processing Network Module (8 x RJ11)
Optional 8-Port FXO Voice Processing Network Module (8 x RJ11)
Optional 8-Port E&M Voice Processing Network Module (8 x RJ48)
Optional 4-Port FXO and 4-Port FXS Voice Processing Network Module (8
x RJ11)
1U x 19" Rack Mountable Standard Chassis
AC Power Supply unit (Free Voltage)
Variuos LEDs, system indicators.
VoiceFinder AP2120 VoIP Gateway supports various routing/bridging
protocols as shown below.
In addition to that, it offers Voice
16
- -
