1.2 Typical System Installation

Figure 1-2
address system.
Paging Amplifier
(up to 25 watts)
802.3at PoE Injector
(High Power Mode with Injector)
Loudspeaker
(8 Ohm)
Operations Guide
illustrates how the VoIP V2 Paging Amplifier is normally installed as part of a public
Figure 1-2. Typical Installation
802.3af Compliant Ethernet Switch
1
Warning
Electrical Hazard:
AC voltages.
GENERAL ALERT
Warning
Electrical Hazard:
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
GENERAL ALERT
2 3 4 5 6
Loudspeaker
VoIP Phone
The VoIP V2 Paging Amplifier enclosure is not rated for any
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
930324M
Product Overview
Typical System Installation
SIP Server
