Seat Width

Fig.15a

Seat Back Height

Fig.16
Proper seat width enables the user to sit comfortably and
prevents problems from developing. While user is seated on
a flat surface, measure from hip to hip. Fig. 15a
The user should have enough room to prevent hips and
thighs from rubbing against the frame. However, the chair
should not be too wide or the user will slide around and
posture could be affected.
Seat width is measured
from the inside walls of
the seat pan. Fig. 15b
Seat back height varies according to chair size. Headrest
extensions are available when extra height is needed to
support the head.
To determine the seat back height, measure from the seat
to the upper part of the head. Fig. 16
FITTING GUIDE
Fig.15b
6
