CONVAID USER'S GUIDE
Fitting Guide
Correct seating and positioning encourages good posture, which in turn aids cir-
culation, breathing and digestion. Please take the time
to properly adjust the chair to fit the user.

Seat Depth

Measure from the most posterior
portion of the buttocks to the back of
the knee. Subtract from that measure-
ment 1-2" to allow adequate clearance
between the seat and the back of the
knee. Fig.14a
5
Fig.14a
To Adjust:
1. Apply wheel locks.
2. Loosen adjustment levers under the
seat by rotating them once in a
counter clockwise direction.
Fig 14b
3. Position yourself facing the chair
and turning the round knobs on the
side of the seat to desired position.
4. Tighten adjustable levers under the
seat by rotating them in a clockwise
direction. Fig. 14c
Fig.14b
Fig.14c
view from bottom of chair
