Convaid Vivo User Manual

..................................................................................................................................
SET-UP AND ADJUSTMENTS
Unfolding
1. Lay chair flat on the ground and unbuckle closure strap. Fig. 1
2. Stand chair on front casters, grasp on to the side of Push Handle and push down on
Seat Tube. Fig. 2
3. Press down firmly on seat tubes to ensure the chair is completely unfolded. Fig. 3
4. Push down on Rear Lock Brace until it locks into a straight position. Fig. 4
5. Swing Footplates down into position. Fig. 5
Fig. 1
Fig. 4
If you have any questions concerning the Vivo, please call your Convaid Representative
Toll free in the US: 888 CONVAID (266-8243)
Phone: (310) 618-0111 • Fax: (310) 618-2166
Vivo
User's Guide
Fig. 2
Fig. 5
888-Convaid (266-8243)
www.convaid.com
Fig. 3
IN0020-ENG-03092016 Printed in U.S.A.
