CONVAID USER'S GUIDE
Positioning Guide
Positioning Belts
The Cuddle Bug comes with either a two-point or a three-point positioning belt.
Both can be attached to the back of the seat (to achieve a 45 degree lap belt
angle) or to the sides of the seat pan (to achieve a 60 degree lap belt angle)
Fig. 19-20. To attach the belts to the chair, open the plastic clip located at the
ends of the positioning belts and thread it through the desired fabric loop, then
press clip together until it clicks shut. Fig. 20-22
Fig.19 Two-point positioning belt
Fig.20 Three-point positioning belt
Fig.21 Seat Pan
Fig.22 Seat Back
9
