Wheel Lock Adjustment

Set wheel locks to locked
position. Push chair with
light pressure on the rear
wheels. If wheel rotates,
adjust tension by turning
the adjustment nut until
wheels no longer rotate
while locked. Fig.69
Caution:
!
Wheel lock
adjustment
should be
inspected
periodically.

Anti-Shimmy

If the front wheels develop
a shimmy, use a wrench to
tighten the stem nut. Adjust
the stem nut clockwise until
the shimmy disappears.
Fig. 70
POSITIONING GUIDE
Fig.69
Fig.70
24
