Depth Adjustable Crotch Strap - Convaid CuddleBug User Manual

To tighten:
Tighten the positioning by pulling on the metal loop located on
the end of the strap. Fig. 23
To loosen:
Grasp buckle and pull away from chair. Fig. 24
Fig.23
Depth Adjustable
Crotch Strap
The 3-point positioning belt comes with a

depth adjustable crotch strap.

To adjust:
1. Locate the small metal retainer on the
crotch strap. Push it through the slot
under the seat until crotch strap is
removed. Fig. 25
2. Push metal retainer through proper hole in
seat and back into the desired slot. Avoid
twisting the strap. Fig 26
POSITIONING GUIDE
Fig.24
Fig.25
Fig.26
10
