Adjustable Contour Headrest

Depth adjustment: Loosen the two nuts located on the upper portion of the
headrest. Slide the front bracket to the desired depth and retighten the nuts. (A)
Height adjustment: Loosen the two nuts located behind the back pan and slide
the back bracket to the desired height then retighten the nuts. (B) Or loosen the
two screws behind the headrest pad and slide the headrest pad your desired
height then retighten the screws. (C)
To achieve a higher headrest height: Loosen and remove the two nuts located
on the upper portion of the headrest. Rotate the front bracket 90-degrees so that
the bracket points upward. Then retighten the nuts. (A)
(A)
(B)
POSITIONING GUIDE
(C)
14
