Hi / Lo Adjustment:
Secure wheel locks prior to adjusting the height of the seat. Squeeze the lever
located on the back of the seat. Using your body weight, press down at a forward
angle. Fig. 48 Release the lever when desired height of seat has been achieved.
Fig. 49
Fig.48
Accessories
Upper Extremity Support Surface (Tray)
The tray is used for feeding and trunk
stabilization. Fig. 50 To attach, slide
tubes located underneath the tray into
armrest receiver. Fig. 51 Once in the
desired position, tighten small knobs
under the armrest.
Fig. 52
FRAME POSITIONING OPTIONS
Fig.49
Fig.50
18
