8. Software Loading Instructions

New and improved software will appear from time to
time on our web site at www.logicube.com. It is
possible to update the operating software in the
field by a user using the Compact Flash Card.
NOTE: Logicube provides a CD Rom that contains
a backup copy of the Logicube SuperSonix
software. This software is already loaded on your
unit.

Loading Software Using the Compact Flash

The new software (a single file always called
sSonix.bin) has to be placed on the root directory of
the Compact Flash (CF). If a CF reader/writer is
available on your computer, sSonix.bin simply
needs to be copied to the root directory, possibly
overwriting the older version that's already there.
Another file called ssfpga.rpd also needs to be on
the root directory of the Compact Flash Card.
NOTE: If a reader is not present, the Logicube
SuperSonix itself, in conjunction with the USB cable
can be configured to behave like a CF reader/writer.
Please refer to "Connecting Through the
Software Setup Menu" in Chapter 7: Compact
Flash (CF) Drive.
Once the new sSonix.bin file is present on the CF, it
is a simple matter to make it "re-flash" the unit:
1. Insert the CF card with the updated software
2. Power up the unit and wait for the main
3. To check the version and date of this
into the SuperSonix
menu to appear. The unit has now updated
itself with the new software
software press the "About" icon at the main
menu screen. 9. Reference
