COMPACT FLASH (CF) CARD

Connecting the CF Drive to Windows via USB

76
Figure 24. Compact Flash (CF) Port Detail.
This is necessary to load new software files to the
CF Drive. There are two methods to connect the
Compact Flash (CF) Drive to Windows through the
USB Port. One is via USB Mode and the other is
through the Software Setup Menu.

Connecting Through USB Mode

1. Make sure your PC is running in Windows
2. Please remove both IDE and/or SATA
3. Connect the USB cable (provided) to a PC
4. From within the Miscellaneous menu press
98 or above.
cables from the Target Drive connectors at
the back of the Logicube SuperSonix unit.
USB slot on one end. Do not attach the
other end to the Logicube SuperSonix yet.
the USB/Firewire icon.
Logicube SuperSonix User's Manual
