Drives - Logicube SuperSonix User Manual

CLONING MODES AND SETTINGS
Settings
24

Drives

Select the Drive Info screen by tapping the Drives
icon. Another screen will come up asking you to
select either the Master Drive or Target Drive icon.
Make your choice and the unit will access the
selected drive and report back the drive's model
number, capacity, geometry, if S.M.A.R.T. is
supported and other information.
Tap the More icon to display a list of partitions
located on the selected drive. The list will include
file name, type and size.
Return to the Drive Information menu by tapping the
OK icon at any time. From there you can select
either Back or Main to return to the Main Menu.
Mirror, Clever, Selective, Master Manager and MD5 Hash
settings are discussed in the Cloning Section. The SAS
Menu is covered in Section 5 under Optional Peripherals.
Diagnostics are covered in section 4.
Master Drive
Figure 11.
Logicube SuperSonix User's Manual
Target Drive
