USB AND FIREWIRE PORTS
68

Using the Solitaire Turbo USB Client

Main Menu Screen

The main menu screen displays the Title Screen
and two menu options: About and Drives.

About Screen

Select the About Screen by clicking the Back
button. It will display the serial number of your unit
along with the software and firmware versions that
are loaded. In addition, the About screen lists all
options currently enabled on the unit and provides
contact information for Logicube Technical Support.
To return to the main menu, simply press the Back
button at any time.

Drive Info

Select the Drive Info screen by clicking the Select
button. Another screen will come up asking you to
select either the <Turbo> or <PCDrive> drive. Click
the Back button to access the drive inside the
SuperSonix. Click the Select button to access the
drive inside the computer.
The unit will then access the drive selected and
report back the drive's model number, capacity,
geometry and other information.
Scroll down to the end of the drive information list to
access the <See more> option. Click the Select
button to display all of the partitions located on that
drive.
To return to the main menu, click the Back button at
any time.

Cloning Modes

Mirror Clone (100%) Step-by-Step

This cloning mode makes a direct, physical copy of
the Master drive. It does not adjust any values or
perform any translation from drive to drive. It simply
copies whatever percentage of the Master drive that
is designated.
1. From the Main Menu Screen, click the SET
2. The white arrow should be pointing to Mode.
button to enter the Settings menu.
Click the SELECT button to change the
mode.
Logicube SuperSonix User's Manual
